  • Page 1 Applikations- LEYBOLD VACUUM Vakuum-Lösungen Unterstützung Service GA 05.280/1 TURBO.POWER 300 Netzgerät für Turbo-Molekularpumpen TURBOVAC Power Supply for TURBOVAC Turbomolecular Pumps Kat.-Nr. / Part No. 800100V0002 Gebrauchsanleitung Operating Instructions...

  • Page 2: Ordering Information

    Description Ordering Information TURBO.POWER 300 800100V0002 The TURBO.POWER 300 is a power supply unit for powering • Supplies the TURBO.DRIVE S with 24 V DC the frequency converter TURBO.DRIVE S with 24 VDC. • Plug & play In connection with the TURBO.DRIVE S the following turbo- •...
  • Page 3 Ø 4 70 116 Fig. 1 Dimensional drawing for TURBO.POWER 300; dimensions in mm GA 05.280/1 - 01/2002...

  • Page 4: Technical Data

    Max. DC current 8.4 A Max. rated power output 200 W Detachable feet Other data Fig. 2 TURBO.POWER 300, connections side Weight 1.5 kg System of protection (EN 60529) IP30 Max. operating altitude 1000 m above sea level Ambient temperature...

  • Page 5: Installation / Connection

    Connect the mains cord. The mains power circuit must be of The TURBO.POWER 300 can be set up on the benchtop. After the earthed type. having unscrewed the feet, the unit may be installed in electri- Switch the turbomolecular pump on and off (see Operating cal cabinets, for example.

  • Page 6: Declaration Of Conformity

    Declaration of Conformity We, Leybold Vakuum GmbH, herewith declare, under referen- For verification in accordance with the low-voltage directive ce to the EMC directive 89/336/EEC, that the power supply 73/23/EEC, the following standard was applied: mentioned below in its original version traded by us, is desi- EN 60950 11/97 gned to comply with the applicable EC directive.
  • Page 7 LEYBOLD VAKUUM GmbH Bonner Strasse 498 (Bayenthal) D-50968 Köln Tel.: (0221) 347-0 Fax: (0221) 347-1250 http://www.leyboldvac.de e-mail:documentation@leyboldvac.de...
