Summary of Contents for Synergy HB-02 Birdroni
- Page 1 HB-02 Birdroni Pre-Assembled Kit Electronics Installation Manual...
- Page 2 About This instruction manual contains the steps needed in order to assemble the HB–02 Birdroni, including the assembli of 3D printed parts, installation of waterproofing, and the installation of the electronics. You can refer to the electronics handbook here. Page Number About………………………………………………...…………………………..
- Page 3 Before we get started: Safety Notices: Take care when handling the 3D printed parts as some contain very sharp edges Please be aware that: 1. Due to the nature of FFF 3D printing some warping may have occured on the face on which the part was printed.
- Page 4 3D Printed Parts Pre-Assembled Body Non-Printed Parts Included in the kit Wax Seal Cable Extensions Electronics: Not Included in the Kit Please Note: These may differer to your electronics. LiPo Battery Transmitter Receiver...
- Page 5 Step 1 Installing the Electronics Prepare the EDF and the hull, remove the • lip of the EDF if it has one. Test fit the EDF in the hull EDF mount by • inserting it from to front of the hull to the rear, notice how much clearance there is between it and the mount walls.
- Page 6 Installing the Electronics Step 4 Get all of the electronics ready, see page 1 for guidance • If your ESC isn’t waterproof it is recommended to waterproof it • Step 5 Plug EDF into the ESC • Place the ESC inside and tuck the •...
- Page 7 Step 8 Test your electronics, • Servo movement, move the servo control and • see the servo movement Please note that you may have to unscrew the • servo arm and reposition it to neutralise the rudder. Test the EDF by increasing the throttle slightly •...
- Page 8 Step 10 Go out and enjoy yourself with your • very own HB-02 Birdroni!
