Page 1: Table Of Contents
Air Driven Motor Drum Can Pump for acids, alkalis and solvents INSTRUCTION MANUAL ■ Air-driven KFC Series Contents 1・・・・・・・・・・・Safety precautions 2・3・4・・・・・・・・Before using the device 5・・・・・・・・・・・Inspection, usage, spec. 6・・・・・・・・・・・Parts description 7・・・・・・・・・・・KFC103A-N Drawings 8・・・・・・・・・・・KFC104A-N Drawings 9・・・・・・・・・・・Warranty and service... -
Page 2: 1・・・・・・・・・・・Safety Precautions
SAFETY PRECAUTIONS This manual contains safety-related information. Please follow it strictly. ・ Before using the device, carefully read the manual (misusing the device may result in accidents). ・ Keep the manual in a safe place and refer to it when necessary. Not following the instructions may result in death or serious injuries. - Page 3 Transferring liquids other than pointed out by AQUASYSTEM may result in accidents, for which the pump maker is not responsible. It is also the user’s responsibility to properly and safely use dangerous liquids.
- Page 4 ★ Use the device in a safe place. Keep the pump away from children. ★ Seek medical attention when necessary. If you suddenly feel worse when operating the pump, immediately discontinue the operation and seek medical attention. ★ Use protective equipment. Wear protective equipment according to liquid’s safety instructions.
- Page 5 ★ Request technical service whenever required. When the device stops operating or operates in a strange manner, immediately turn it off and contact technical service. Do not use broken equipment, as it may result in accidents. ★ Do not cause shock to device’s main body. It may result in pump’s malfunction, breakdowns and leakage.
- Page 6 INSPECTION 1. Check the air supply pressure 2. Make sure the pump has contact with liquid, which is going to be transferred (running the pump in a constant dry state is strictly forbidden). 3. Make sure the air supply regulation valve is closed. 4.
-
Page 7: 6・・・・・・・・・・・Parts Description
PARTS DESCRIPTION KFC103A-N KFC104A-N 1 Motor’s main body Motor’s main body 2 Air coupler Air coupler 3 Drum Can Adapter (Plastic, G2) Drum Can Adapter (Plastic, G2) 4 Valve (Plastic, 3/4) Valve (SUS, 3/4) 5 Reinforced PVC Hose (2m・φ25) SUS304 Hose (2m・φ25) 6 PP Nozzle SUS304 Nozzle... -
Page 8: 7・・・・・・・・・・・Kfc103A-N Drawings
KFC103A-N DRAWINGS ７... -
Page 9: 8・・・・・・・・・・・Kfc104A-N Drawings
KFC104A-N DRAWINGS... -
Page 10: 9・・・・・・・・・・・Warranty And Service
② Product’s breakdown has been reported within 1 year from the date of purchase, but: The product has been misused. ⚫ The product has been repaired/serviced, however, not by AQUASYSTEM. ⚫ The product has not been stored or maintained properly.
