JVC AV-28WFR1EKS Service Manual page 3

POWER & DEF. PW BOARD ASS'Y(Page 41~42)
PW BOARD No. SJK-2504A-U2
! Symbol No.
PARTS No.
R2403 QRE141J-123
R2414 QRE121J-3R9Y
R2467 QRG039J-120
R2551 QRT039J-3R3
R2552 QRT039J-3R3
!
R2554 QRZ9021-1R5
!
R2556 QRZ9011-4R7
!
R2557 QRZ9021-100
C2461 QETN2AM-475Z
!
C2521 QFZ0200-352
!
C2523 QFP32GJ-223
C2524 QFM72DK-104
C2525 QFZ0199-354
C2526 QFZ0199-254
C2528 QFZ0199-683
C2529 QFZ0199-104
C2532 QFZ0199-334
C2542 QFZ0199-204
C2543 QFZ0199-154
C2561 QFLC1HJ-683Z
T2521 CE42549-001J1
!
T2551 QQH0065-002-I2
T2561 QQR0898-001
L2461 QQLZ028-822
L2521 QQLZ028-101
D2403 1SS133-T2
D2555 MTZJ12C-T2
D2556 MTZJ12C-T2
K2501 CE41433-001Z
K2502 CE41433-001Z
!
PC2901 TLP721F(D4-GR)
SJK-2508A-U2
PARTS No.
QRA14CF-3091Y
QRE121J-100Y
QRL039J-330
QRT039J-1R5
QRT039J-1R5
QRZ9022-R47
QEZ0195-475Z
QFZ0200-282
QFP32GJ-183
QFM72DK-563
QFZ0197-304
QFZ0197-473
QFZ0197-434
QFZ0197-184
QFV71HJ-184Z
QQH0089-001
QQH0898-001
QQLZ027-821
QQLZ028-501
TLP421F/D4-GR/
No. 51695B
PARTS NAME
CR
CR
OM R
MF R
MF R
FR
FUSI. RESISTER
FUSI. RESISTER
E CAP.
2800pF 1.5kVH ±3％
MPP CAP.
PP CAP.
M CAP.
MPP CAP.
MPP CAP.
MPP CAP.
MPP CAP.
MPP CAP.
MPP CAP.
MPP CAP.
M CAP
BRIGE COIL
FBT
DEF.TRANSF.
CHOKE COIL
CHOKE COIL
SI.DIODE
ZENER DIODE
ZENER DIODE
BEADE CORE
BEADE CORE
I.C. (PH.COUPLER)
AV-28WFR1EKS
AV-28WFR1EK
DESCRIPTION
3.09kΩ 1/4W F
10Ω 1/2W J
33Ω 3W J
1.5Ω 3W J
1.5Ω 3W J
0.47Ω 1W J
Delete
Delete
4.7μF 50V M
0.018μF 400V J
0.056ΜF 200V K
Delete
0.3μF 250V J
Delete
0.047μF 250V J
Delete
0.43μF 250V J
0.18μF 250V J
0.18μF 50V J
Delete
Delete
Delete
Delete
Delete
Delete
