True EXECUTIVE EZ CHAIR E43500 Operating Instructions

E X E C U T I V E E Z C H A I R
OPERATING INSTRUCTIONS
1. To Adjust Seat Height:
While seated, lean forward and reach under the right
side of the chair to find the handle. Lift the handle and
raise your body up slightly to allow the chair to rise to
the desired height. To lower the seat, lift the handle
while applying more weight downward on the seat. The
chair will descend until the handle is released or the
chair reaches the bottom position.
2. To Operate Tilt Lockout:
While seated, reach under the right side of the chair to
find the height adjustment handle. Pull the handle all
the way out (away from the gas lift) to allow the chair to
tilt backwards. To lock the chair in the vertical position,
sit upright and push the handle in towards the gas lift.
3. To Adjust Tension on The Tilt
Mechanism:
Reach under the front center of the chair, grasp the
round knob and turn counter- clockwise to make the tilt
mechanism firmer (stiffer). To make the tilt mechanism
less firm, twist the knob clockwise until the desired
resistance is found.
4. To Disassemble the back cushion:
Remove the black inserts from the top of the arm holes
located on both arm frames. Insert the allen key into
arm hole positions on both sides of the arms and tilt the
back cushion forward. Both pins must be disengaged at
the same time. After it has released from the arms, fold
the back cushion onto the seat cushion.
Model #: E43500
