REVELL PINEWOOD DERBY SKATEBOARD RACER SET Instructions

WWW.REVELL.COM
S S S
KATEBOARD KATEBOARD KATEBOARD
Read the entire instruction
sheet before beginning
assembly. Adult supervision
is required!
1
Assembly Instructions
2
Detail the Body
needed. Do not scuff the fi nal coat.
R R R S S S
ACER ACER ACER ET ET ET
INSTRUCTIONS
Contents
1. (1) Precut Wood Block
2. (4) Axles
3. (4) Wheels
1. Sand the body
using coarse (120
grit) sandpaper
fi rst, followed by
medium (220 grit)
paper. Optional:
to smooth out the
racer, use fi ner
paper.
2. Test fi t the
wheels and axles
for proper fi t.
Adjust as needed.
Set them aside for
later use.
1. Clean all dust
from the racer.
Apply a thin coat of
1
paint as evenly as
possible. When dry,
use fi ne sandpaper
to lightly scuff
the paint. Apply
additional coats as
2. Test fi t the
decals with the
backing still on.
Once you are sure
of their placement,
peel off the
backing and apply.
4. (1) Stick-On Chassis Weight
5. (2) Decal Sheets
6. (1 each) Sandpaper 120 & 220 Grit
3
Installing the Wheels and Axles
between the inside of the wheel and the outside of the racer.
parallel to the edge of the adjustment tool.
WARNING:
CHOKING HAZARD —
Small parts.
Not for children under 3 years of age.
3. Use a foam
brush 1 to apply an
even layer of clear
1
coat. Extra layers
can be applied if
needed.
1. Place a wheel on
each of the axles,
and press them
into the axle slots
on the bottom of
the racer.
2. Space each
wheel to have
a small gap.
Place the wheel
adjustment tool
between the racer
and the wheel.
Move the axle and
wheel until the
tool fi ts snugly
3. Place the kit
on a smooth, fl at
surface. Place a
wheel adjustment
2
tool with the
camber check
section against the
face of the wheel.
Adjust each axle to
make the wheels
2
