- Page 1 WHTS1114LSSA Washing Machine User’s Manual Lavatrice Manuale utente Wasmachine Gebruiker Handleiding Document Number 2820526521_EN/ 30-04-18.(15:34)
-
Page 2: General Safety Instructions
General safety instructions This section includes security instructions which may help prevent the injuries and material damage risks. All kinds of warranties shall be invalid if these instructions are not observed. 1.1 Life and property safety Never place the product on a carpet-covered floor. Electrical parts will get overheated since air cannot circulate from under the device. -
Page 3: Electrical Safety
Do not forget to close the loading door when leaving the room where the product is located. Store all detergents and additives in a safe place away from the reach of the children by closing the cover of the detergent container or sealing the detergent package. -
Page 4: Important Instructions For Environment
Important instructions for environment 2.1 Compliance with WEEE Directive This product complies with EU WEEE Directive (2012/19/EU). This product bears a classification symbol for waste electrical and electronic equipment (WEEE). This product has been manufactured with high quality parts and materials which can be reused and are suitable for recycling. -
Page 5: Technical Specifications
Technical specifications Complying Commission Delegated Regulation (EU) No 1061/2010 Supplier name or trademark SMEG Model name WHTS1114LSSA Rated capacity (kg) Energy efficiency class / Scale from A+++ (Highest Efficiency) to D (Lowest Efficiency) A+++ Annual Energy Consumption (kWh) Energy consumption of the standard 60°C cotton programme at full load (kWh) 1,210 Energy consumption of the standard 60°C cotton programme at partial load (kWh) -
Page 6: Appropriate Installation Location
4.1 Installation • Apply to the nearest authorised service agent for the installation of your product. • Preparation of the location and electrical, tap water and waste water installations at the place of installation is under customer's responsibility. • Make sure that the water inlet and discharge hoses as well as the power cable are not folded, pinched or crushed while pushing the product into its place after installation or cleaning procedures. -
Page 7: Connecting Water Supply
4.1.4 Connecting water supply The water supply pressure required to run the product is between 1 to 10 bars (0.1 – 1 MPa). It is necessary to have 10 – 80 liters of water flowing from the fully open tap in one minute to have your machine run smoothly. Attach a pressure reducing valve if water pressure is higher. -
Page 8: Adjusting The Feet
4.1.6 Adjusting the feet CAUTION: In order to ensure that the product operates more silently and vibration-free, it must stand level and balanced on its feet. Balance the machine by adjusting the feet. Otherwise, the product may move from its place and cause crushing and vibration problems. -
Page 9: Preparing Laundry For Washing
4.2 Preparation 4.2.1 Sorting the laundry * Sort laundry according to type of fabric, color, and degree of soiling and allowable water temperature. * Always obey the instructions given on the garment tags. 4.2.2 Preparing laundry for washing • Laundry items with metal attachments such as, underwired bras, belt buckles or metal buttons will damage the machine. -
Page 10: Using Detergent And Softener
4.2.6 Using detergent and softener When using detergent, softener, starch, fabric dye, bleacher and decolorant, descaling agents; read the manufacturer's instructions written on the package and follow the dosages specified. Use measuring cup if available. The detergent drawer is composed of three compartments: –... - Page 11 Using liquid detergents If the product contains a liquid detergent cup: • Put the liquid detergent container into the compartment no “2”. • If the liquid detergent lost its fluidity, dilute it with water before putting it into the detergent container.
-
Page 12: Tips For Efficient Washing
4.2.7 Tips for efficient washing Clothes Light Colours and Black/Dark Delicates/ Colours Whites Colours Woolens/Silks (Recommended (Recommended (Recommended temperature (Recommended temperature temperature range based temperature range range based on soiling level: range based on soiling level: on soiling level: cold based on soiling 40-90 cold -40... -
Page 13: Operating The Product
4.3 Operating the product 4.3.1 Control panel 1 - Programme Selection knob 6 - On / Off button 2 - Spin speed adjustment button 7 - Start / Pause button 3 - Temperature Adjustment button 8 - End Time Setting button 4 - Display 9 - Auxiliary Function buttons 5 - Program Follow-up indicator... -
Page 14: Programme And Consumption Table
4.3.3 Programme and consumption table Auxiliary functions Selectable Programme temperature range °C 60** 1.210 1400 60-Cold Cotton Eco 60** 0.920 1400 60-Cold 40** 0.910 1400 60-Cold Baby Cycle 2.70 1400 90-30 Shirts 1.40 • • • 60-Cold Mixed 0.90 1000 •... -
Page 15: Programme Selection
4.3.4 Programme selection 1 Determine the programme suitable for the type, quantity and soiling level of the laundry in accordance with the "Programme and consumption table". Programmes are limited with the highest spin speed appropriate for that particular type of fabric. When selecting a programme, always consider the type of fabric, colour, degree of soiling and permissible water temperature. - Page 16 • Silk Care With its special angle controlled washing movement and heating profile it washes your sensitive silky clothes delicately. Wear and tear and discoloration that might occur on your silky clothes are minimized by slowing down the fall of laundry from the drum. •...
-
Page 17: Temperature Selection
• Delicate Wash With its very soft washing movement and heating profile it washes your sensitive clothes delicately. You can wash your delicate clothes that are natural and acrylic such as silky or woolen and that are made with synthetic fiber such as polyester and bear W mark on the washing label as sensitive as dry cleaning. The need for dry cleaning chemicals is eliminated and environmental pollution is reduced. -
Page 18: Auxiliary Function Selection
If you want to spin your laundry after the Rinse Hold function: - Adjust the Spin Speed. - Press Start / Pause / Cancel button. The programme resumes. Machine spins the laundry by discharging the water. If you want to discharge the water at the end of the programme without spinning, use No Spin function. No change can be made in programmes where spin speed adjustment is not allowed. -
Page 19: Time Display
• Steam Use this programme to reduce the creases and ironing times of a small amount of unspotted cotton, synthetic or mixed laundry. Load only half of the capacity stated for the selected programme. When this auxiliary function is selected, it is normal to hear boiling noises since the steam generator boils water to produce steam. -
Page 20: Loading Door Lock
4.3.11 Loading door lock There is a locking system on the loading door of the machine that prevents opening of the door in cases when the water level is unsuitable. "Door Locked" symbol appears on the display when the loading door is locked. 4.3.12 Changing the selections after programme has started Adding laundry after the programme has started: If the water level in the machine is suitable when you press Start / Pause button, loading door symbol will... - Page 21 To deactivate the childproof lock: Press and hold Auxiliary Function button 2 for 3 seconds. After the countdown as “CL 3-2-1” on the display is over, "CL On" disappears from the display. 4.3.14 Cancelling the programme The programme is cancelled when the machine is turned off and on again. Press and hold On / Off button for 3 seconds.
-
Page 22: Maintenance And Cleaning
4.4 Maintenance and cleaning Service life of product extends and frequently experienced problems will be reduced if it is cleaned at regular intervals. 4.4.1 Cleaning the detergent drawer Clean the detergent drawer at regular intervals (every 4-5 washing cycles) as shown below in order to prevent accumulation of powder detergent in time. -
Page 23: Draining Remaining Water And Cleaning The Pump Filter
Close the taps. Remove the nuts of the water intake hoses to access the filters on the water intake valves. Clean them with an appropriate brush. If the filters are too dirty, remove them from their places with a pliers and clean in this way. Take out the filters on the flat ends of the water intake hoses together with the gaskets and clean thoroughly under running water. -
Page 24: Troubleshooting
Troubleshooting Problem Reason Solution Program does not start after Start / Pause / Cancel button was not pressed. • *Press the Start / Pause / Cancel button. closing the door. It may be difficult to close the loading door in case of •... - Page 25 Problem Reason Solution Programme time does not There might be unbalanced load in the machine. • Automatic unbalanced load detection system countdown. (*) might be activated due to the unbalanced distribution of the laundry in the drum. Machine does not switch to There might be unbalanced load in the machine.
- Page 26 Problem Reason Solution Laundry became stiff after Insufficient amount of detergent is used. • Using insufficient amount of detergent for the washing. (**) water hardness can cause the laundry to become stiff in time. Use appropriate amount of detergent according to the water hardness. Detergent is put in the wrong compartment.
