Owner's Manual / Installation Manual
Manuel de l'utilisateur / Manuel d'installation
Bedienungs- & Installationsanleitung
Manuale del proprietario e manuale di installazione
Gebruiks- & Installatiehandleiding
Manual del propietario / Manual de Instalación
Bruks- och installationsanvisning
Manual do Proprietário e Manual de Instalação
TTX7503z
CeNET TV TUNER (PAL/SECAM)
TUNER TV CeNET (PAL/SECAM)
CeNET-TV-TUNER (PAL/SECAM)
SINTONIZZATORE TV CeNET (PAL/SECAM)
NET TV-TUNER MET CeNET AANSLUITING (PAL/SECAM)
SINTONIZADOR DE TV CeNET (PAL/SECAM)
CeNET TV-TUNER (PAL/SECAM)
TUNER TV CeNET (PAL/SECAM)
TTX7503z
MODEL
VHF
UHF
Expand TV Tuner
12V
GROUND
45.75MHz-224.25MHz
471.25MHz-855.25MHz
ISO
8mmMAX
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Clarion TTX 7503Z TTX7503Z TTX7503Z
Summary of Contents for Clarion TTX 7503Z TTX7503Z TTX7503Z
- Page 1 Owner’s Manual / Installation Manual Manuel de l’utilisateur / Manuel d’installation Bedienungs- & Installationsanleitung Manuale del proprietario e manuale di installazione Gebruiks- & Installatiehandleiding Manual del propietario / Manual de Instalación Bruks- och installationsanvisning Manual do Proprietário e Manual de Instalação TTX7503z CeNET TV TUNER (PAL/SECAM) TUNER TV CeNET (PAL/SECAM)
-
Page 2: Table Of Contents
7. PRECAUTIONS POUR L’INSTALLATION DES CABLES ... 15 8. CONNEXION DE CABLAGE ... 16 TTX7503z Deutsch Wir danken Ihnen für den Kauf dieses Clarion- Produkts. • Vor Einbau und Anschluß des Geräts unbedingt die Einbau- und Betriebsanleitung vollständig durchlesen. • Bewahren Sie diese Betriebsanleitung nach dem Durchlesen gr iffbereit an einem geeigneten Ort (z.B. -
Page 3: Precautions
1. PRECAUTIONS • This equipment uses DC 12 V only. Do not use this equipment on 24 V vehicles such as large trucks. • When driving, keep the TV tuner volume down to a level where you can hear sounds from outside the vehicle. -
Page 4: Set Countries List
3. SET COUNTRIES LIST The TV area function can be used to set the following country areas. Note: When the TV receiving country is set to France. If the TV receiving country has been set to France, the receivable channels range from L5 to L12, 21 to 69 Set Countries Display Title ALBANIA AUSTRIA... -
Page 5: Specifications
4. SPECIFICATIONS Reception channels: VHF CCIR 2 to 12 ch[CCIR “L” L5 to L12 ch (when receiving country has been UHF CCIR 21 to 69 ch Antenna input: 75 Ω unbalanced voltage: 14.4 V Grounding: Negative terminal grounding Power consumption: 0.8 A or less External dimensions: 178 mm (Width) ✕... -
Page 6: Troubleshooting
5. TROUBLESHOOTING The following symptoms may not be the result of a breakdown, so perform the remedy suggested below before contacting your Dealer for repairs. Symptom No power Wiring is incomplete. No image Parking brake is not engaged. Unclear image from Image output for front and rear seat monitor rear is connected in reverse. -
Page 7: Installation
6. INSTALLATION • Disconnect the battery negative cable before connecting the wiring. • If you are making holes in the vehicle body in order to install the unit, first confirm the position of pipes, tanks and electrical wiring to avoid contact and interference. •... -
Page 8: Wiring Connections
TV displays an image. • If the PKB cable is not connected to the side brake, some units may not operate. For connection of the monitor (such as the Clarion VRX633R, sold separately). To parking brake Supplied PKB cable Terminal (∗... -
Page 9: Precautions
Clarion Co., Ltd. All Rights Reserved. Copyright in © 2005:Clarion Co., Ltd. 280-8225-00 Printed in Japan / Imprimé au Japon / Gedruckt in Japan / Stampato in Giappone 2005/2 (D•K) ZT-4651E Gedrukt in Japan / Impreso en Japón / Tryckt i Japan /...
