Sentinel™ EFI-BFZ
FIGURE 1: CURRENT SENSOR MOUNTED ON MULTI-CORE CABLE SYSTEM
EARTH
FIGURE 2: CURRENT SENSOR MOUNTED ON SINGLE-CORE CABLE SYSTEM
EARTH
CURRENT
SENSOR
CURRENT
SENSOR
(CT300)
Version 3.2
User's Manual
TERMINATION
L1 L2 L3
SCREEN
CURRENT
SENSOR
OUTGOING CABLE
EQUIVALENT CIRCUIT
TERMINATION
L1 L2 L3
SCREEN
CURRENT
SENSOR
OUTGOING CABLE
EQUIVALENT CIRCUIT
