Sentinel™ EFI-BFZ
User's Manual
4.1.1 MULTI-CORE CABLE SYSTEM
The Sentinel™ EFI ships with a standard sized (CT100) current sensor, which is suitable for most
multi-core cable systems. A larger current sensor (CT150) is also available but must be specified at
time of order. The flexible sensor core is mounted on the screened part of the cable, below the
stripback point. The core is wrapped around the cable and the cable-tie is pulled tight as far as it will
go. A second cable-tie is used to hold the core firmly onto the cable. The cable screen is turned back
underneath the core and then terminated to earth as shown in the Figure 1.
Version 3.2
Page 5 of 15
