UPC 3536 Assembly Instructions

PARTS BAG

PART
Screw Posts
Slatwall Adapters
Hex Nuts
Wall Togglers
Phillips Head Screws
Card Clips
TOOLS REQUIRED: Flathead Screwdriver (Slatwall)
Drill with 3/8" Drywall Bit & Phillips Screwdriver (Drywall)

PARTS LIST

PART
Rack

Slatwall Assembly

Align hole in Slatwall Adapter (B) with
1
back side of hole in Rack (F). Prongs extend
back toward Slatwall and up. Attach using
Screw Post (A) from front and Nut (C)
on back.
Insert Card Clips (F) into
2
Rack (G).
Revised 09/14/15
ASSEMBLY INSTRUCTIONS
UPC #3536
Quantity Reference
6 A
6 B
6 C
6 D
6 E
32 F
Quantity Reference
2 G
C
B
47-3/4" 2-Tier PETG with 2/3 Exposure (2-Per)
B
A
NOTE: Assemble for EITHER Slatwall or Drywall, not both.
C
B
A
D
C
E
G
C
B
F
A
G
F
A
Page 1 of 2
