Clas Ohlson 38-2497 Manual

Network Card PC-card
Art.no. 38-2497, model: 10/100M
Please read the entire instruction manual before using and
save it for future use.
We apologise for any text or photo errors and any changes
of technical data.
If you have any questions concerning technical problems
please contact our Customer Service Department.
Product Description
- 100 Base-TX with a transferring speed up to 10/100
Mbps (full duplex).
- The network card connects to the network via a TP cable
with a RJ-45 module connector.
- Supported by Windows 98SE, ME, 2000 and XP.
- Plug and Play.
Installation
Note! The following instructions are for Windows XP
with an installed service pack 2 that can differ some
depending on the user's settings.
1. Insert the network card into an empty card slot in your laptop
and connect the network cable for the network card.
2. Windows XP will find and install the network card
automatically when the computer is turned on. No
external drivers needed.
GREAT BRITAIN For consumer contact, please visit www.clasohlson.co.uk and
click on customer service. Internet: www.clasohlson.co.uk
ENGLISH
Control the status of the network card
The network card is shown in "device manager" when it is
installed. Click on Start/Settings/Control panel/System/
Computer hardware/Device manager. Select "Network
card" from the list and then right click on the network card
you have installed.
Indicator Light
The network card has two Led's for control and for troubleshooting:
"F"
- The LED marked lights up when the card is functioning and
has contact with the network.
"L"
- The LED marked blinks when the network card is
transferring data via the RJ45 outlet.
Disposal
Follow local ordinances when disposing of this product.
If you are unsure about how to dispose of this product
contact your municipality.
Specifications
Standard: IEEE802.3x (10Base-T) (100Base-TX)
Connection: 1x RJ45
