FLOORslim
5140-030120
5140-040120
5141-030120
5141-040120
DE
Bedienungsanleitung
EN
User manual
FR
Mode d'emploi
ES
Instrucciones de uso
IT
Istruzioni per l'uso
5142-030120
5142-040120
5143-030120
5143-040120
5144-030120
5144-040120
5145-030120
5145-040120
shop.dotlux.de --> item-no --> Downloads
5146-030120
5146-040120
5147-030120
5147-040120
02/2021

Advertisement

loading
Need help?

Need help?

Do you have a question about the FLOORslim 5140-030120 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for DOTLUX FLOORslim 5140-030120

  • Page 1 FLOORslim 5140-030120 5142-030120 5144-030120 5146-030120 5140-040120 5142-040120 5144-040120 5146-040120 5141-030120 5143-030120 5145-030120 5147-030120 5141-040120 5143-040120 5145-040120 5147-040120 Bedienungsanleitung User manual Mode d‘emploi shop.dotlux.de --> item-no --> Downloads Instrucciones de uso Istruzioni per l‘uso 02/2021...
  • Page 2 10 W 113 mm 132 mm 30 mm 20 W 153 mm 160 mm 30 mm 30 W 174 mm 195 mm 35 mm 50 W 192 mm 239 mm 44 mm 10 W 20 W 122mm(4.8") 150mm(5.9" ) 40mm(1.57") 60mm(2.36"...
  • Page 3 120°...
  • Page 4 5140-030120 5140-040120 ARTIKEL-NR. 5144-030120 5144-040120 ABMESSUNGEN 113 x 132 x 30 mm 113 x 132 x 30 mm LEISTUNGSAUFNAHME 10 W 10 W LICHTFARBE 3000 K 4000 K ABSTRAHLWINKEL 120° 120° EINGANGSSPANNUNG 220 – 240 V AC 220 – 240 V AC TEMPERATURBEREICH -30 °C –...
  • Page 5 Die Lichtquelle dieser Leuchte ist nicht er- setzbar; wenn die Lichtquelle ihr Lebensdau- erende erreicht hat, ist die gesamte Leuchte zu ersetzen. Konformität Hiermit erklärt DOTLUX GmbH, dass dieses Produkt den EU-Richtlinien EMC 2014/30/ EU, LVD 2014/35/EU, RoHS 2011/65/EU und der Ökodesign-Richtlinie 2009/125/EG ent- spricht.
  • Page 6 Verpackung angegebenen Leuchtmittel. erklärung ist unter der folgenden Internet- Folgende umweltbedingte Einflüsse können adresse verfügbar: unerwünschte Wirkungen auf die Oberflä- https://www.dotlux.de/konformitaetserk- che des Produktes haben: saurer Regen und laerungen/ Boden, hoher Salzgehalt in der Luft, Reini- gungsmittel, Dünger (inbesondere in Blu-...
  • Page 7 Beachten Sie für die Montage und die War- einen wichtigen Beitrag. tung die nationalen Montage- und Unfallver- hütungsvorschriften. Serviceadresse DOTLUX GmbH Arbeiten Sie niemals bei anliegender Richard-Stuecklen Str. 7, 91781 Weissenburg Spannung an der Leuchte. Achtung Tel: +49 9141 / 4051 0...
  • Page 8 Symbole Schutzart / Schutzklasse Die Leuchte hat einen Schutzleiteranschluss. Schließen Sie Schutz- den Schutzleiter (grün-gelbe Ader) an die gekennzeichnete Er- klasse I dungsschraube an. Schutz- Die Leuchte ist besonders isoliert und darf nicht an einen klasse II Schutzleiter angeschlossen werden. Schutz- Die Leuchte darf nur an Sicherheitskleinspannung angeschlos- klasse III...
  • Page 9 5140-030120 5140-040120 ITEM-NR. 5144-030120 5144-040120 DIMENSIONS 113 x 132 x 30 mm 113 x 132 x 30 mm POWER CONSUMPTION 10 W 10 W COLOR TEMPERATURE 3000 K 4000 K BEAM ANGLE 120° 120° INPUT VOLTAGE 220 – 240 V AC 220 –...
  • Page 10 Conformity DOTLUX GmbH hereby declares that this product complies with the EU Directives EMC 2014/30/EU, LVD 2014/35/EU, RoHS 2011/65/EU and the Ecodesign Directive...
  • Page 11: Other Symbols

    Internet ces (e.g. pesticides). Only the lamps stated address: on the packaging may be used. https://www.dotlux.de/konformitaetserk- laerungen/ Other Symbols Always follow the symbols on the packaging and in the instructions. The characters and...
  • Page 12 Service Address Do not install the lamp when volta- ge is applied the the lamp. Caution: DOTLUX GmbH Danger to life! Richard-Stuecklen Str. 7, 91781 Weissenburg Tel: +49 9141 / 4051 0 Electrical connections may only be Fax: +49 9141 / 4051 999 carried out by a qualified electrici- info@dotlux.de...
  • Page 13 Symbols IP protection / Protection class The luminaire has a connection for a protective earth conduc- Protection tor. Connect the protective earth conductor (green-yellow class I wire) to the corresponding marked earth screw. Protection The luminaire has special insulation and must not be connected class II to a protective earth conductor.
