- Page 1 Quick Reference Guide JANUS 2010 Battery Charger ™ P/N 058430-003...
-
Page 2: Industry Canada Compliance
The JZ2010 is UL Listed (UL 1950), CSA Certified (C22.2 #950) and TUV “GS” Licensed (EN 60950 and DIN VDE 0805) for safety when powered by an external Intermec power supply. UL, CSA, and TUV have approved Intermec power supply 058399 for use with the JZ2010. -
Page 3: Table Of Contents
Contents Introduction 5 Battery Charger Parts and Functions 5 Top Panel 5 Back Panel 6 Installing the Battery Charger 7 Mounting the Battery Charger 7 Connecting the Power Supply 7 Using the Charger for the First Time 8 Charging Battery Packs 8 Discharging Battery Packs 10 Battery Status Lights 11 Battery Troubleshooting 12... -
Page 5: Introduction
The JZ2010 battery charger is an accessory for the JANUS™ 2010 reader. The charger allows you to: charge up to four JANUS 2010 battery packs at one time. discharge up to four JANUS 2010 battery packs at one time. Battery Charger Parts and Functions... -
Page 6: Back Panel
JANUS 2010 Battery Charger Quick Reference Guide Back Panel The back panel of the charger has two parts: Discharge button Use this button to discharge one or more battery packs. You only need to discharge a battery pack that has lost its capacity to hold a charge. -
Page 7: Installing The Battery Charger
Connecting the Power Supply The battery charger uses the Intermec Part No. 058399 power supply, which has a detachable power cord. The power supply operating range is 100 to 240 VAC at 47 to 63 Hz. To connect the power supply, attach the power supply to the connector on the back panel of the charger and plug the power supply into an AC outlet. -
Page 8: Using The Charger For The First Time
JANUS 2010 Battery Charger Quick Reference Guide Using the Charger for the First Time You are ready to use the battery charger once the power supply is connected and plugged in. If there are no J2010 battery packs inserted in the charger, the battery LEDs on the top panel are all turned off. - Page 9 Note: The optimum battery temperature to begin charging battery packs is 68°F (20°C). Battery packs charged at 68°F (20°C) have a higher charge capacity and hold more charging cycles than battery packs charged at a higher temperature. JANUS 2010 Battery Charger Quick Reference Guide Battery Pack...
-
Page 10: Discharging Battery Packs
JANUS 2010 Battery Charger Quick Reference Guide Discharging Battery Packs The battery charger is designed to maximize battery life and prevent the loss of battery capacity due to the memory effect associated with NiCad batteries. Usually it is not necessary to discharge a battery pack before charging it. If a battery pack is unable to hold a full charge, you can use the charger to discharge the battery pack before charging it. -
Page 11: Battery Status Lights
If you have any problems, refer to “Battery Troubleshooting” later in this quick reference guide. = off JANUS 2010 Battery Charger Quick Reference Guide The charger is waiting for a battery or there is no power to the charger. -
Page 12: Battery Troubleshooting
JANUS 2010 Battery Charger Quick Reference Guide Battery Troubleshooting Battery LEDs Problem The battery pack must always be between 50 F and 104 F (10 C Discharge and Ready and 40 C) to begin charging. If LEDs flash alternately the battery pack temperature is with Charge LED.
