TABLE OF CONTENTS IMPORTANT SAFETY INSTRUCTIONS······················································P2 SATETY NOTES FOR BATTERIES AND CHARGER·····································P4 SPECIFICATIONS···················································································P4 PACKAGE CONTENTS············································································P4 FUNCTION DESCRIPTION········································································P5 OPERATING PROCEDURES····································································P6 MAINTENANCE······················································································P10 COMPONENT LIST AND EXPLODED VIEW················································P11... -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS When using electric tools, machine or equipment, basic safety instructions should be always followed to reduce the risk of fire, electric shock and injury. KEEP WORKING AREA CLEAN. Clean areas to prevent injuries. CONSIDER YOUR WORK AREA ENVIRONMENT. Don’t use power tools in damp, wet, or poorly lit locations. - Page 4 IMPORTANT SAFETY INSTRUCTIONS MAINTAIN TOOLS WITH CARE. Keep tools clean for better and safer performance. Follow instructions regarding lubricating, safe performance and changing accessories. Keep handles dry, clean and free from oil and grease. REMOVE ALL ADJUSTING KEYS AND WRENCHES. Make it a habit to check that keys and adjusting wrenches are removed from any rotating tool before using.
-
Page 5: Satety Notes For Batteries And Charger
SATETY NOTES FOR BATTERY AND CHARGER RIGHT TEMPERATURE FOR CHARGING. Room temperature must be higher than 32°F and lower than 122°F. DO NOT CHARGE IF THE CHARGER’S CORD OR PLUG IS DAMAGED. Charging with a damaged cord may result a fire and electrical shock. If the charger is damaged in any way, have it repaired by a trained serviceman. -
Page 6: Function Description
FUNCTION DESCRIPTION Description 1/2’’ Square Drive Metal Gear Housing Direction Button (Forward / Stop / Reverse) Variable Speed Trigger Switch Rubber Handle Battery Release Button Battery Pack LED Light Charger Important If you encounter any quality issues regarding this product, please feel free to contact us via email service@avidpowertool.com.We will be always here to help. -
Page 7: Operating Procedures
OPERATING PROCEDURES BATTERY PACK 1. The battery is not fully charged. You’d better let it charge for 1-2 hours before the first use. Normal charging time is 1-2 hours when the battery is completely dead. 2. Replace a new battery when tool performance begins to diminish; Severe heat is most destructive to a battery;... - Page 8 How do you know if the battery is fully charged ? Normal charging time is 1 to 2 hours when the battery is completely dead. The red light will turn off and the green light remains lit once the battery is fully charged.
- Page 9 OPERATING PROCEDURES When the machine is obstructed, please turn off the switch right away and check if the work piece is right. An obstruction may cause the machine motor to be burned. Notice: This tool is cordless and does not need to be connected to a power supply. CAUTION: Do not expose either the tool or charger to the rain or water.
- Page 10 OPERATING PROCEDURES If the tool shows signs of decreased power, stop and recharge the battery. Using the tool to do heavy work when the battery is weak drains the battery very quickly and may damage the battery. Use the variable speed only for starting VARIABLE SPEED You can vary the spindle rotation speed by modulating finger pressure on the trigger.
-
Page 11: Maintenance
OPERATING PROCEDURES LED WORKING LIGHT The impact wrench has 1 LED lights to illuminate the work area and improve vision when working in areas with insufficient light. The LED light will be turned on or off accompanied by situation of the trigger switch. -
Page 12: Component List And Exploded View
COMPONENT LIST AND EXPLODED VIEW Description Qty. Gear box sheet Screw ST5x30 Gear box Bearing Switch push button Spindle washer Switch Main spindle LED transparent cover Impact block assembly Right housing Planet gear Screw ST4.2x16 Screw M4x10 Hook Left housing Washer Gear ring Bearing 6002—2Z...
