Page 1: Table Of Contents
LP50100DC READ AND SAVE THESE INSTRUCTIONS LoProfile DC Installer: leave this guide with homeowner. Ventilation Fan INSTALLATION GUIDE Easy installation Table of Contents Warnings and Cautions Typical Installation Installation Operation Cleaning and Maintenance Troubleshooting © 2019 Broan-NuTone LLC... -
Page 2: Warnings And Cautions
Page 2 LP50100DC Installation Guide WARNING CAUTION TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR . For general ventilating use only. Do not use to exhaust INJURY TO PERSONS, OBSERVE THE FOLLOWING: hazardous or explosive materials and vapors. 1. Use this unit only in the manner intended by the manufacturer. 2. -
Page 3: Installation
Page 3 LP50100DC Installation Guide Installation Tools needed Materials needed • Power screwdriver with a Phillips bit • 4" round metal ducting recommended for best performance. Use of other ducting is acceptable but may impact performance. • Phillips screwdriver • Roof cap or wall cap (built-in damper recommended) •... - Page 4 Page 4 LP50100DC Installation Guide Installation Install in Wall or Ceiling Wire (3 places) - OR - Screw through housing on opposite side Wall Tighten Screw into housing to secure mounting Ceiling Install Ducting 4" Ducting Tape Insert tab into slot in housing.
- Page 5 Page 5 LP50100DC Installation Guide Installation Connect Wires • Run 120VAC electrical wiring to the installation location. • Use proper UL-approved connectors to secure wiring to the Knockout Plate. • Connect wires as shown in wiring diagram. Connect wires Attach cable clamp to Knockout Plate.
- Page 6 Page 6 LP50100DC Installation Guide Installation Insert Mask and Finish Wall or Ceiling h is in t f r o il is p lâ g in g in t r e s t r s id t io c le il ic in t s t a...
-
Page 7: Operation
Page 7 LP50100DC Installation Guide Operation Cleaning and Maintenance To Operate Fan To Clean Use an ON/OFF switch to operate this ventilator. For quiet and efficient operation, long life and attractive Do not use a speed control. appearance, remove Grille and vacuum interior of unit with a dusting brush attachment.
