Page 1: Table Of Contents
LP80 & LP110 READ AND SAVE THESE INSTRUCTIONS Lo Profile Installer: leave this guide with homeowner. Ventilation Fan INSTALLATION GUIDE Table of Contents Warnings and Cautions Typical Installation Installation Operation Easy installation Cleaning and Maintenance Troubleshooting Service Parts © 2018 Broan... -
Page 2: Warnings And Cautions
Page 2 LP80 & LP110 Installation Guide WARNING CAUTION TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR . For general ventilating use only. Do not use to exhaust INJURY TO PERSONS, OBSERVE THE FOLLOWING: hazardous or explosive materials and vapors. 1. -
Page 3: Installation
Page 3 LP80 & LP110 Installation Guide Installation Tools needed Materials needed • Power screwdriver with a Phillips bit • 4" round metal ducting recommended for best performance. Use of other ducting is acceptable but may impact performance. • Phillips screwdriver •... - Page 4 Page 4 LP80 & LP110 Installation Guide Installation Install in Wall or Ceiling Wire (3 places) - OR - Screw through housing on opposite side Wall Tighten Screw into housing to secure mounting Ceiling Install Ducting 3" Ducting Tape 4" to 3" 4"...
- Page 5 Page 5 LP80 & LP110 Installation Guide Installation Connect Wires • Run 120VAC electrical wiring to the installation location. • Use proper UL-approved connectors to secure wiring to the Knockout Plate. • Connect wires as shown in wiring diagram. Connect wires Attach cable clamp to Knockout...
- Page 6 Page 6 LP80 & LP110 Installation Guide Installation Insert Mask and Finish Wall or Ceiling h i s i n t f r o il i s g i n p l â t r e s t r i d e t i o c l e il i c...
-
Page 7: Operation
Page 7 LP80 & LP110 Installation Guide Operation Troubleshooting To Operate Fan Symptom: The fan does not run. Use an ON/OFF switch or speed control to operate this • Check for an open fuse or circuit breaker in the building’s ventilator. -
Page 8: Service Parts
Page 8 LP80 & LP110 Installation Guide Service Parts Key No. Part No. Description 77001277 Duct Connector Assembly 79140014 Grille Spring (2 included) 77001280 Grille Assembly (includes 2 grille springs) 77001297 Capacitor (LP80) 1100050 Capacitor (LP110) 77001298 Wire Panel Assembly 79110158 4”...
