- Page 1 RF702N4 I S1 RF715N4AS1...
-
Page 2: Safety And Warning Information
Contents Safety and warning information Cleaning and care Installing your new appliance Helpful hints and tips Description of the appliance Troubleshooting Display controls Disposal of the appliance Using your appliance Safety and warning information For your safety and correct usage, before installing and first using the appliance, read this user manual carefully, including its hints and warnings. - Page 3 Keep all packaging away from children as there is risk of suffocation. If you are discarding the appliance, pull the plug out of the socket, cut the connection cable (as close to the appliance as you can) and remove the door to prevent children playing from suffering an electric shock or from closing themselves inside it.
-
Page 4: Replacing The Led
type recommended by the manufacturer. WARNING — The refrigerant and insulation blowing gas are flammable. When disposing of the appliance, do so only at an authorized waste disposal centre. Do not expose to flame. WARNING —When positioning the appliance, ensure the supply cord is not trapped or damaged. - Page 5 It is dangerous to alter the specifications or modify this product in any way. Any damage to the cord may cause a shortcircuit, fire, and/or electric shock. Electrical safety 1. The power cord must not be lengthened. 2. Make sure that the power plug is not crushed or damaged. A crushed or damaged power plug may overheat and cause a fire.
- Page 6 Do not place food products directly against the air outlet on the rear wall. Store pre-packed frozen food in accordance with the frozen food manufacture’s instructions. The appliances manufactures storage recommendations should be strictly adhered to. Refer to relrelevant instructions for storage.
- Page 7 Before maintenance, switch off the appliance and disconnect the mains plug from the mains socket. Do not clean the appliance with metal objects, steam cleaner, ethereal oils, organic solvents or abrasive cleansers. Do not use sharp objects to remove frost from the appliance. Use a plastic scraper.
-
Page 8: Installing Your New Appliance
Installing your new appliance Before using the appliance for the first time, you should be informed of the following tips. Warning! For proper installation, this refrigerator must be placed on a level surface of hard material that is the same height as the rest of the flooring. - Page 9 Then pass the refrigerator laterally. If you the bottom feet may need to be adjusted. do not need to remove the appliance You can adjust them manually by hand or doors, go to ‘Installing the water lines’ on by using a suitable spanner. page 11.If you need to remove the doors, To allow the doors to self-close, tilt the continue below.
- Page 10 3. Remove the 3 screws (B) fixed on the Re-attaching the fridge doors hinges with a Wrench (8mm) and 1 ground To reattach the fridge doors after you have screws (C) attached to the hinge with moved the appliance to its final location, Philips (+) screwdriver.
- Page 11 5. Pull out the freezer door and lift it up in the direction of the arrow. 2. Take out the upper freezer drawer (A) by lifting it up from the rail system. Re-assembling the freezer door To reattach the drawer after you moved appliance final location,...
- Page 12 and Outlet of the water filter. 3. Insert the 2 clips in the proper position as the figure shown below, and confirm that each clip holds the water line firmly. Connecting the filter inlet line to the Note ： ： ： ： The water lines must be fully inserted into water supplier the filter to prevent water leaking.
- Page 13 if the lines are fully inserted where the connector leaked. If not, please install them again, and make sure that the lines are fully inserted. Note: After connect the filter outlet line with the refrigerator(as shown in the diagram below), please dispense several cups of The initial dark discoloration of water is water to flush the lines before use.
-
Page 14: Description Of The Appliance
Description of the appliance Note ！ ！ ！ ！ Due to unceasing modification of our products, your refrigerator may be slightly different from this instruction manual, but its functions and using methods remain the same. To get the best energy efficiency of this product, please place all shelves, drawers and baskets on their original position as the illustration above. - Page 15 Note ！ ！ ！ ！ Due to unceasing modification of our products, your refrigerator may be slightly different from this instruction manual, but its functions and using methods remain the same. To get the best energy efficiency of this product, please place all shelves, drawers and baskets on their original position as the illustration above.
-
Page 16: Display Controls
Display Controls Use your appliance according to the following control guidelines. The control panel on the top cover shows in the diagram below, it may be different depending on the model. When the appliance is powered on for the keep your food longer. first time, the backlighting of the icons on The super freeze option allows you to the display panel starts working. - Page 17 that can be correctly used in your When super cool function is on, you can refrigerator. touch the S uper Cool button again to “ ” After you change a new water filter, ensure switch it off. The fridge will not retain the to touch and hold the I ce On Super Cool function when power off.
-
Page 18: Using Your Appliance
appliance. The door alarm can also be When the door of fridge or freezer has cleared by closing the door. been opened for over 2 minutes, the door NOTE: High temperature setting will accelerate alarm will sound. In case of door alarm, food waste. - Page 19 dispenser lever in the suggested position （ o ptional ） . To remove all of them, refer and press it. to page 10 for disassembly instruction. Automatic Icemaker (optional) Automatic Icemaker make automatic 。 Note: Don't push the dispenser lever forward without cup, it may cause the water leak from the dispenser.
- Page 20 Order Compartments Target storage Appropriate food Type temp.[°C] Eggs, cooked food, packaged food, fruits and Fridge +2~+8 vegetables, dairy products, cakes, drinks and other foods which are not suitable for freezing. ≤ 18 Seafood (fish,shrimp,shellfish),freshwater aquatic (***)*-Freezer products and meat products (recommended for 3 months ,the longer the storage time,the worse the taste and nutrition),suitable for frozen fresh food.
-
Page 21: Cleaning And Care
Cleaning and care hygienic reasons appliance fridge freezer with a weak solution of (including exterior and interior accessories) bicarbonate of soda, and then rinse with should be cleaned regularly at least every warm water using a wrung-out sponge or two months. cloth. -
Page 22: Helpful Hints And Tips
door. Wash seal with a mild detergent and completely dry should the appliance be warm water. Rinse and dry it thoroughly powered on after cleaning. Replacing the LED light Warning: The LED light must be replaced by a competent person. If the LED light is damaged, follow the steps below: 1. -
Page 23: Troubleshooting
out of use, let the appliance run at least 2 hours on the higher settings before putting Hints for the storage of frozen food food in the compartment. Ensure that frozen food has been stored Prepare food in small portions to enable correctly by the food retailer it to be rapidly and completely frozen and Once defrosted... - Page 24 It is normal that the freezer is not operating during the defrost cycle, or for a short time after the appliance is switched on to protect the compressor. The interior may need to be cleaned Odours from compartments Some food, containers or wrapping cause odours. The sounds below are quite normal: Compressor running noises.
-
Page 25: Disposal Of The Appliance
The control systems has disabled the lights due to the door being kept open too long, close and reopen the door to reactivate the lights. Did you wait for 12 hours after installation of the water supply line before making ice? If it is not sufficiently cool, it may take longer to make ice, such as when first installed. - Page 26 Correct Disposal of this product This marking indicates that this product should not be disposed with other household wastes throughout the EU. To prevent possible harm to the environment or human health from uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse of material resources. To return your used device, please use the return and collection systems or contact the retailer where the product was purchased.
