- Page 1 KM Admin Tool | USER MANUAL Table of Contents SECTIONS KM Admin Tool User Manual KVM Remote RS-232 Control | QUICK SETUP GUIDE HDC21381 Rev. 1.0...
- Page 2 TABLE OF CONTENTS Introduction Creating a Custom Layout File Using the KM Admin Tool Uploading a Custom Layout File Using the KM Loader Tool KM Admin Tool | USER MANUAL...
- Page 3 The KM supports any display layout defined by the user. This enables users to align displays in in any physical layout they want and configure the KM to support this layout. Layout examples: KM Admin Tool | USER MANUAL...
- Page 4 However, if the desired layout does not appear in the table above, it is necessary to use the KM Admin Tool to create it. The purpose of this manual is to explain how to use the KM Admin Tool to set custom layouts.
- Page 5 Creating a Custom Layout File Using the KM Admin Tool As stated earlier, a display layout that does not appear in the Secondary display, on the left, AND – table of presets, needs to be created. The first step is to create Primary display, on the right a custom layout file using the KM Admin Tool.
- Page 6 Creating a Custom Layout File Using the KM Admin Tool Click Create Project. The KM Project Setup dialog opens: • Mouse Speed: Makes mouse movements faster or slower. In this example, select 5 – Default. • Mouse Acceleration: Makes mouse accelerate faster or slower.
- Page 7 Creating a Custom Layout File Using the KM Admin Tool At the bottom, click Next Step. At the bottom, click Next Step. The KM Project Description dialog opens: The Computer 1 Setup dialog opens: Type a description that explains the custom layout. In In this example: •...
- Page 8 Creating a Custom Layout File Using the KM Admin Tool Fill out as follows: 10. In this example, fill out like for Computer 1, as follows: At the bottom, click Next Step. 11. At the bottom, click Next Step. The Computer 2 Setup dialog opens:...
- Page 9 Creating a Custom Layout File Using the KM Admin Tool 12. In this example, Computer 3 has two displays, the first for Note: To set the MS H/V Coordinates, use the following diagram: the primary display and the second for the secondary display.
- Page 10 Creating a Custom Layout File Using the KM Admin Tool The following examples show how to make the MS H/V Above Coordinates settings for different primary-secondary relative If the secondary display (=1920 x 1080) is ABOVE the primary positions: display, type the SECONDARY display’s HORIZONTAL value as: Left 0 and VERTICAL value as: (minus) -1080.
- Page 11 Creating a Custom Layout File Using the KM Admin Tool 13. In this example, fill in as follows: 14. At the bottom, click Next Step. The Place the displays dialog opens, showing all • For Display 1 (Primary), type 24 for Display Diag and computers configured: 1920 and 1080 for Display Resolution (H/V).
- Page 12 Creating a Custom Layout File Using the KM Admin Tool 16. At the bottom, click Complete Setup. The Browse for Folder dialog opens: 17. Select a folder to save the file to, and note this location for future reference. KM Admin Tool | USER MANUAL...
- Page 13 PC. This creates the KM Loading Tool icon on the desktop. • A HighSecLabs KM (in this example, the 4-port SM40N-3) Double-click on the KM Loading Tool icon. • An A-A USB cable The KMConfigLoader dialog opens: •...
- Page 14 9, download and install the KM Multi Display Drivers onto the relevant computers. In this example, install the KM Multi Display Drivers onto Computer 3 (it has a KM Admin Tool | USER MANUAL...
