- Page 1 Dual DSU-DP Option Module & Plug-On Board Option Module PN 1200127L1#HS Plug-On Board PN 1200128L1 USER MANUAL 61200.128L1-1A April 1996...
- Page 2 901 Explorer Boulevard P.O. Box 070020 Huntsville, AL 35807 Phone: (205) 971-8000 Fax: (205) 971-8699 © 1996 ADTRAN, Inc. All rights reserved. Printed in USA.
- Page 3 FEDERAL COMMUNICATIONS COMMISSION RADIO FREQUENCY INTERFERENCE STATEMENT: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equip- ment is operated in a commercial environment.
- Page 4 Table of Contents...
-
Page 5: Table Of Contents
DDS Overview ..................... 3 Switched 56 Overview ................3 Chapter 2 Installation .................. 5 Unpack and Inspect ................... 5 Shipped by ADTRAN .................. 5 Adapter Cables .................... 5 Provided by Customer ................5 Installing the Option Module ................6 Placement of the Option Module ............... 6 Power Connection .................. - Page 6 Table of Contents DIC (Disregard Incoming Call) ..........18 PRN (Program Number) ............. 18 RLN (Request List of Numbers) ..........18 Chapter 3 Operation Overview ......................19 Menu Structure ..................19 MenuOperation ..................21 Chapter 4 Configuration Configuration Overview .................. 23 Local and Remote Configuration .............
- Page 7 Table of Contents Chapter 6 Testing & Troubleshooting Test Overview ....................55 Initiating a Test ..................56 DSU-DP Test Operation ................57 Tests Using the TEST Pattern Generator........... 57 Remote Test ..................60 Troubleshooting ....................61 Messages from the DSU/CSU ..............61 Troubleshooting New Installs..............
- Page 8 Table of Contents Chapter 7 Status Selection STATUS Display ....................77 DSU Operational Status ................78 DDS Network Status ................. 78 Network Rate ..................... 79 DTE Rate/Mode ..................79 DTE Control Leads and Status ..............80 Appendix A AT Commands ................ 81 Appendix B Default Configuration Profiles ..........
- Page 9 Table of Contents Figures Figure 1-1 Sample Point-to-Point Application for Dual DSU-DP ....2 Figure 2-1 Installing the Option Module ............6 Figure 2-2 Attaching the Plug-On Board ............7 Figure 2-3 DSU-DP Option Module Rear View ..........8 Figure 3-1 TSU 100 Main Menu ..............20 Figure 4-1 Setting Network Rate Options ............
- Page 10 Table of Contents Figure C-1 DSU to Modem Interconnet ............85 Figure D-1 EIA-232 Connector ............... 87 Figure E-1 DSU-DP Configuration Menu Tree ..........91 Tables Table 2-A Pin Assignments for Primary EIA-232 Cable ....... 9 Table 2-B Pin Assignments for Primary V.35 Cable ........10 Table 2-C Configuration Methods ..............
-
Page 11: Chapter 1 Introduction
Chapter 1. Introduction Chapter 1 Introduction PRODUCT OVERVIEW The ADTRAN Dual DSU-DP provides a reliable, high speed data connection for customer data terminal equipment (DTE) through the ADTRAN TSU/HSU DS0 port. It provides compatibility with digital data service (DDS), or Switched 56 network (SW56) services. The... - Page 12 Chapter 1. Introduction Figure 1-1 shows a sample point-to-point application for the Dual DSU-DP . Router DSU III AR DSU III DBU DSU III DBU ENTER ENTER R D C D A L M T S T R D C D A L M T S T SHIFT SHIFT SHIFT...
-
Page 13: Dds Overview
Chapter 1. Introduction DDS Overview Digital Data Service (DDS) is a nationwide service that allows interconnection and transport of data at speeds up to 64 kbps. The local exchange carriers provide the local loop service to DDS customers and may provide data for routing Inter-LATA to an interexchange carrier. - Page 14 Chapter 1. Introduction Dual DSU-DP User Manual 61200.128L1-1...
-
Page 15: Chapter 2 Installation
Dual DSU-DP for repair or for verification of damage during shipment. Shipped by ADTRAN The following items are included in the ADTRAN ship- ment: • The Dual DSU-DP Option Module or Dual DSU-DP Plug-On Board •... -
Page 16: Installing The Option Module
Chapter 2. Installation INSTALLING THE OPTION MODULE It is not necessary to turn off the power to the TSU/HSU when installing the option module because it is hot swappable. The plug-on board must be attached to a hot swappable option module if you wish to install it while the TSU/HSU is powered on. -
Page 17: Attaching The Plug-On Board
Chapter 2. Installation Attaching the Plug-On Board Figure 2-2 is representative of the action required for proper attachment of a plug-on board to the option module. Perform the following steps to install the plug- on board: 1. Hold the plug-on board above the option module. 2. -
Page 18: Rear Panel
Chapter 2. Installation REAR PANEL The rear panel contains two high-density subminiature DTE connectors which provide V.35 or EIA-232 inter- faces via custom cables. Pin assignments for the DTE connections are listed in the section DTE Data Connec- tion in this chapter. The DSU-DP rear panel is shown in Figure 2-3. -
Page 19: Dte Data Connection
Chapter 2. Installation DTE DATA CONNECTION T he DT E should be connected to either the E IA-232 DT E cable or the C C IT T V.35 DT E cable. T he maximum cable lengths recommended are 50 feet for the E IA-232, and 100 feet for the C C IT T V.35 ( note: ADT RAN-adapter cables are six feet in length) . - Page 20 Chapter 2. Installation Table 2-B Pin Assignments for Primary V.35 Cable HD Pin # CCITT Description 1 0 1 Protective G round (PG ) 1 0 2 Signal Ground (SG) 1 0 5 Request to Send (RS) 1 0 6 Clear to Send (CS) 1 0 7 Data Set Ready (SR)
