SURGE PROTECTION

Isolated Loop Circuit Protector

when used with one or more IG1CM Modules

UL497B 90 VDC Breakdown

Route coaxial cables through knockout located in the bottom
section of the enclosure. Connect the incoming (unprotected)
cable to the upper threaded connector on the IG1C module.
Connect the protected cable (to the equipment) to the lower
threaded connector of the module.
Repeat for each set of coaxial cables to be protected.
IN (unprotected)
OUT (protected)
IN (unprotected)
OUT (protected)
INTERMATIC INCORPORATED

Model IG1C3R

SPRING GROVE, ILLINOIS 60081
LISTED
27
TM
Optional
Modules
154IG24461
