  • Page 1 R5120 Non-Contact Voltage and Magnetic Field Detector Instruction Manual www.REEDInstruments.com GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com...
  • Page 2: Table Of Contents

    Table of Contents Introduction ....................3 Product Quality ................... 3 Safety ......................3 Features ...................... 4 Included ...................... 4 Specifications ..................... 5 Instrument Description ................6 Operating Instructions ................6-7 Turning the Detector ON/OFF ............... 6 Turning the Flashlight ON/OFF .............. 6 AC Voltage Detection ................
  • Page 3: Introduction

    Introduction Thank you for purchasing your REED R5120 Non-Contact Voltage and Magnetic Field Detector. Please read the following instructions carefully before using your instrument. By following the steps outlined in this manual your detector will provide years of reliable service. Product Quality This product has been manufactured in an ISO9001 facility and has been calibrated during the manufacturing process to meet stated...
  • Page 4: Features

    Features • Check receptacles or insulated wire for presence of AC voltage • Quickly determine the presence of magnetic fields • Double insulated housing for increased safety • Audible (buzzer) and visual (LED) indicators • Built-in flashlight • Pocket clip •...
  • Page 5: Specifications

    Specifications Voltage Range: Low Voltage Mode: 24 to 1000VAC High Voltage Mode: 90 to 1000VAC Frequency Range: 50 to 60Hz Magnetic Field Detection: Built-in Flashlight: Pocket Clip: Alarm: Yes (audio/visual) Auto Shut-off: Yes (after 5 minutes) Drop Tested: Yes, 6.6' (2m) Low Battery Indicator: Power Supply: 2 x AAA batteries...
  • Page 6: Instrument Description

    Instrument Description R5120 Non-Contact Voltage and Magnetic Field Detector CAT IV 1000V~ 1. NCV Sensor Head 5. Power Button 2. Flashlight 6. Flashlight Button 3. Sensing Signal LED 7. Pocket Clip 4. Mode Status Indicator Light 8. Battery Cap Operating Instructions Turning the Detector ON/OFF Press the power button to turn the detector on.
  • Page 7: Ac Voltage Detection

    AC Voltage Detection Place the NCV sensor head near the test object or the power socket with AC voltage. When AC voltage is detected, the red LED in the tip and audible alarm will turn on. High/Low Voltage Detection Modes When the detector is powered on the red indicator light on the panel will light up indicating the default voltage detection range is set to High (90 to 1000VAC).
  • Page 8: Battery Replacement

    Battery Replacement Unscrew the battery cap counterclockwise as shown at right picture, and then replace the batteries according to the polarity indication. Tighten the battery cap clockwise and the buzzer will beep twice to indicate the completion of the replacement. Product Care To keep your instrument in good working order we recommend the following: •...
  • Page 9: Product Warranty

    REED Instruments total liability is limited to repair or replacement of the product. REED Instruments shall not be liable for damages to goods, property, or persons due to improper use or through attempts to utilize the instrument under conditions which exceed the designed capabilities.
