Ultimate
Curve
Assemble instructions

Advertisement

loading
Need help?

Need help?

Do you have a question about the Ultimate Curve and is the answer not in the manual?

Questions and answers

Related Manuals for Amcargobikes Ultimate Curve

Summary of Contents for Amcargobikes Ultimate Curve

  • Page 1 Ultimate Curve Assemble instructions...

  • Page 2: Front Fender

    There shouldn’t be any space between them. 2. Front Fender Parts needed: M5*12 Inner hexagon screw, 8 pcs M5 self-locking nut, 8 pcs φ5 washer, 8 pcs Notice: The fender should stay at the center. Amcargobikes - Phone: - Mail: contact@amcargobikes.co.uk +45 5047 9845...
  • Page 3 Amcargobikes - Phone: - Mail: contact@amcargobikes.co.uk +45 5047 9845...
  • Page 4 Amcargobikes - Phone: - Mail: contact@amcargobikes.co.uk +45 5047 9845...
  • Page 5 3. Steering Stopper 4. Front Brake Disc M5*8 plum screw, 12 pcs Notice: The direction of disc arrow should be same as the running direction of wheel. Amcargobikes - Phone: - Mail: contact@amcargobikes.co.uk +45 5047 9845...

  • Page 6: Front Wheels

    5. Front Wheels Notice: The profile of tires should match the direction of bike wheel running. Amcargobikes - Phone: - Mail: contact@amcargobikes.co.uk +45 5047 9845...
  • Page 7 6. Divider of Hydraulic Brake M5*25 Inner hexagon screw, 2 pcs M5 self-locking nut, 2 pcs φ5 washer, 4 pcs Notice: Please make sure that the directions of left brake and right brake are right. Amcargobikes - Phone: - Mail: contact@amcargobikes.co.uk +45 5047 9845...

  • Page 8: Front Brake

    7. Front Brake M6*15 Inner hexagon screw, 4 pcs φ6 washer, 4 pcs Amcargobikes - Phone: - Mail: contact@amcargobikes.co.uk +45 5047 9845...

  • Page 9: Front Light

    8. Front Light M5*16 Inner hexagon screw, 2 pcs M5 self-locking, 2 pcs φ5 washer, 2 pcs Amcargobikes - Phone: - Mail: contact@amcargobikes.co.uk +45 5047 9845...
  • Page 10 Put the 30205 bearing underneath the front frame while the 30204 bearing above the front frame. Then the φ27 washer and then φ18 spring washer. Fix the M18 slotted nut and then the pin. Bend the two legs of the pin to avoid slipping. Amcargobikes - Phone: - Mail: contact@amcargobikes.co.uk +45 5047 9845...
  • Page 11 10. Fastening Screws of Canopy Bracket and Steering Bar M8*20 Inner hexagon screw, 6 pcs M8 nut, 6 pcs φ8 washer, 6 pcs Amcargobikes - Phone: - Mail: contact@amcargobikes.co.uk +45 5047 9845...
  • Page 12 φ6 washer, 16 pcs Notice: The two front corner brackets are shorter than the two rear ones. Fix the screws first and then fasten the screws after all the wood plates are properly fixed. Amcargobikes - Phone: - Mail: contact@amcargobikes.co.uk +45 5047 9845...
  • Page 13 Amcargobikes - Phone: - Mail: contact@amcargobikes.co.uk +45 5047 9845...
  • Page 14 After the wood plates and corner brackets are fixed at the right angles properly. Then you can fix all the screws tightly and fasten them together. Amcargobikes - Phone: - Mail: contact@amcargobikes.co.uk +45 5047 9845...
  • Page 15 13. Bottom Board and Front Frame M6*70 cross screw with round head, 5 pcs M6 self-locking nut, 5 pcs φ6 washer, 10 pcs Amcargobikes - Phone: - Mail: contact@amcargobikes.co.uk +45 5047 9845...
  • Page 16 Notice: White ones are for the front, while red ones are for the rear. The torque force of screws shouldn’t be too large, because it may break the screw thread of reflectors. Amcargobikes - Phone: - Mail: contact@amcargobikes.co.uk +45 5047 9845...
  • Page 17 15. Heel Block and Side Wood Plate M5*35 cross screw, 4 pcs M5 cap nut, 4 pcs φ5 washer, 8 pcs Amcargobikes - Phone: - Mail: contact@amcargobikes.co.uk +45 5047 9845...
  • Page 18 M6 self-locking nut, 4 pcs to fix the safety belt and cable holder) φ6 washer, 8 pcs M6*20 cross screw, 6 pcs M6 self-locking nut, 8 pcs φ6 washer, 16 pcs Amcargobikes - Phone: - Mail: contact@amcargobikes.co.uk +45 5047 9845...
  • Page 19 Amcargobikes - Phone: - Mail: contact@amcargobikes.co.uk +45 5047 9845...
  • Page 20 17. Canopy Plastic Holder M6*10 Inner hexagon screw, 6 pcs M8 lock nut, 6 pcs φ6 washer, 6 pcs φ8.2 washer, 6 pcs Amcargobikes - Phone: - Mail: contact@amcargobikes.co.uk +45 5047 9845...
  • Page 21 18. Side board and Footrest M6*20 Philip's head screw, 4 pcs M6 cap nut, 4 pcs φ6 washer, 8 pcs Amcargobikes - Phone: - Mail: contact@amcargobikes.co.uk +45 5047 9845...

  • Page 22: Steering Bar

    19. Steering Bar Connector, brake lever (please notice the left and right), display, bell and shifter. Amcargobikes - Phone: - Mail: contact@amcargobikes.co.uk +45 5047 9845...
  • Page 23 Notice: After assembly, please check whether they are fastened very tightly and closely. and avoid oil leak. The sequence of these parts should be right. In the process of assembly, there shouldn’t be any phenomenon of oil leak. Amcargobikes - Phone: - Mail: contact@amcargobikes.co.uk +45 5047 9845...
  • Page 24 21. Seat post, Saddle and Rubber Band Notice: Please adjust the saddle to the proper angle. Amcargobikes - Phone: - Mail: contact@amcargobikes.co.uk +45 5047 9845...
  • Page 25 22. Pedal Notice: Please realize there’s difference between the left and right. Amcargobikes - Phone: - Mail: contact@amcargobikes.co.uk +45 5047 9845...
  • Page 26 23. Canopy Bracket and Bush Amcargobikes - Phone: - Mail: contact@amcargobikes.co.uk +45 5047 9845...
  • Page 27 24. Canopy Enjoy your new Ultimate Curve - Cargobike! Amcargobikes - Phone: - Mail: contact@amcargobikes.co.uk +45 5047 9845...
