Summary of Contents for YANGZI YZ-X7

  • Page 1 Final Interpretation Rights Belong To Yangzi Industry Anhui Yangzi Industrial Technology Co., Ltd...
  • Page 2 Model Number: YZ-X7 YZ-X7 Floor Scrubber Operating Manual ANHUI YANGZI INDUSTRIAL TECHNOLOGY CO., LTD.
  • Page 3 YZ-X7...
  • Page 4 YZ-X7 This manual provides the necessary machine operation and maintenance instructions. Please read and understand this manual carefully before operating or using the machine. When ordering replacement parts, refer to the parts manual included with the machine. Determine your machine model or serial number before selecting parts or accessories. You can order parts and accessories from any authorized service center or dealer by phone or by mail.
  • Page 5: Table Of Contents

    YZ-X7 Contents Notes ....................01 Machine operation display ............02 Receiving machine ................ 03 Open Package install the battery Machine cleaning mode .............. 04 Brush and clean pad ..............05 Machine Installation ..............06 Mount suction stripping assembly Install brush / cleaning pad Machine Operation ...............
  • Page 6: Notes

    YZ-X7 Notes This machine is for industrial and commercial purposes, specifically for cleaning indoor hard floors and not for other purposes. Please use the recommended cleaning pads and brushes and available floor cleaners for this machine. All operators must read, understand, and observe the following safety precautions.
  • Page 7 YZ-X7 The following information indicates potential hazards to operators or equipment: for safety: 1. Do not operate the machine: A contact with flammable liquid or near flammable gas, otherwise may cause explosion or flash fire. — Unless trained and authorized to operate the machine.
  • Page 8: Receiving Machine

    YZ-X7 Receiving machine Remove the machine packing l. carefully check the machine box for damage. Immediately to the freight industry. Check the shipping contents. If there are any missing items, please contact the seller. Freight content: ● 6v Battery 4 Standard ●...
  • Page 9: Machine Cleaning Mode

    YZ-X7 Note: Apply a thin layer of metal-free lubricating oil or protective spray to avoid battery corruption. After the bottle is complete, check the power scale of the battery power meter. Charge the battery as required. Machine cleaning mode Cleaning method: Manually control the water valve to adjust the water flow of the water tank and scavenger to the floor.
  • Page 10: Install Brush / Cleaning Pad

    YZ-X7 Knob Connect the vacuum suction pipe to the suction pickup assembly. Check and adjust properly Install brush and cleaning pad Description: For the recommended brush and cleaning mat, refer to this manual or consult with your local authorized dealer.
  • Page 11: Water Tank Drainage

    YZ-X7 During the machine operation Warning: Fire or explosion hazard. Do not pick up flammable materials or active metals. 1. Each cleaning path overlaps by 5 cm. 2 Continue the machine to damage the ground. If water suction water, the ground has drag marks, wipe with a rag tape to remove La ban. Clean up in advance to prevent drag marks.
  • Page 12: Battery Charging

    YZ-X7 Battery charging NOTE: In order to extend the battery life and ensure the best performance of the machine, the battery must be charged for less least 30 minutes. Do not leave the battery unused for a long time. The following charging instructions apply to the charger attached with this machine.
  • Page 13: Machine Maintenance

    YZ-X7 Machine maintenance The machine works best as long as daily, weekly and monthly maintenance procedures are indeed observed. Warning: Risk of electric shock. Disconnect the battery wiring before maintaining the machine. Daily maintenance After each use of the Drain out and clean the sewage tank Remove and flush the floating filter screen located in the sewage tank Drain water tank and flush hot water tank not above 60 °...
  • Page 14: Handling Machine

    YZ-X7 Handling machine When handling machines using a truck or trailer, always follow the following binding procedures: Raise the brush head to the handling position. Mount the machine using the recommended loading pad. Close the front of the machine in front of the truck or trailer. After the machine is released, drop the brush head and turn the key to the closed position.
  • Page 15: Troublting

    YZ-X7 Troublting Stopic Reason Solutions Battery dead battery Battery charging Machine Battery fault Replacement of the battery Working Battery wiring is loose Tighten the battery wiring Main fuse burning off Replace the fuse Brush head goes up from the Lower the brush head...
  • Page 16 YZ-X7 Sewage tank is full Drainage and drainage sewage tank Wear of suction strip Replace water suction strip efficienc y of Water suction blockage Remove blocked debris recycling sewage Damage seal seal sewage Replace seal strip damaged Vacuum motor failure...
  • Page 17 YZ-X7 Working time 3-4h Machine Weight 380kg Machine Size 1650*1200*1420...
  • Page 18: Cm117 Fault Description

    YZ-X7 CM1172 fault description I. LCD interface interface (1) Status display (2) Power display (3) Walking motor status, Walking motor current display (4) water suction motor status, water suction motor current display, water suction push rod status display (5) Brush plate motor status, brush plate motor current display, brush plate push rod status...
  • Page 19 YZ-X7 II. Failure description Status Display Other Display Causes Solutions Open circuit on the Check CM6012 The CM6012 serial None serial port line for the controller serial line port is not connected CM6012 controller Open circuit on the Check CM6020...
  • Page 20 YZ-X7 1. charging suppression The 1. is in a charged Precharging fault None 2. controller fault state 3. battery Low 2. controller internal fault 3. Battery Charging...
  • Page 21 YZ-X7 High battery voltage None High battery voltage Battery voltage mismatch Water suction and brush 1. sewage tank is full 1. emptying the water Sewage tank is full plate and corresponding 2. sewage switch short from the sewage tank push tter delay stop circuit 2.
