XF1 PRO | MANUAL
Injection moulded polyurethane grips
Construction made of metal and forging carbon fiber
Dashboards and LED bars are compatible with SimHub
4.3-inch IPS LCD with 800x480 pixels and 60 FPS
18 RGB LEDs with adjustable brightness and color
Optional non-contact clutch and optional paddles
70mm quick release holes and bolt holes

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XF1 PRO and is the answer not in the manual?

Questions and answers

Related Manuals for LEOXZ XF1 PRO

Summary of Contents for LEOXZ XF1 PRO

  • Page 1 XF1 PRO | MANUAL Injection moulded polyurethane grips Construction made of metal and forging carbon fiber Dashboards and LED bars are compatible with SimHub 4.3-inch IPS LCD with 800x480 pixels and 60 FPS 18 RGB LEDs with adjustable brightness and color...
  • Page 2 This racing wheel is designed for simulation use only. • Leoxz is responsible for revising and explaining this manual, and reserves the right to make changes or corrections to the information and explanation provided without prior notice and without any responsibility.

  • Page 3: What's Included

    What's included • XF1 Pro Steering Wheel • USB-XS9 Cable • Custom Stickers • M3 Allen Key • Nylon Tweezers Note: The M3 allen key can only be used to adjust the paddle and remove the front knob for easy sticking of stickers.

  • Page 4: Usb Connection

    USB Connection XF1 Pro can only be connected via USB cable and requires a minimum input power of 5V 0.8A to ensure proper operation. Otherwise, unexpected errors may occur. The USB-XS9 cable will ensure a stable and reliable connection. Note: Make sure that the USB-XS9 cable is aligned...
  • Page 5 QR Installation The XF1 Pro has 12 mounting holes with a diameter of 70mm for quick release installation, including 6 through holes and 6 threaded holes. It supports a maximum diameter of 88mm for the quick release. Through Holes Threaded Holes （6XΦ5)
  • Page 6 Install QR From Outside Note: Using any QR must and can only be powered and signaled to the XF1 Pro via the USB-XS9 cable.
  • Page 7 Interface 18 RGB LEDs compatible with Simhub 800x480 IPS LCD compatible with Simhub 16 Momentary button 2 Thumb rotary encoder 2 Front rotary encoder with push button 2 Multi-directional joystick with integrated encoder 2 Non-contact hall shifter paddle 2 Optional non-contact hall clutch paddle 2 Optional non-contact hall option paddle Note: Keep in mind that on the page for the Windows USB Gaming device, some of the buttons will not show.

  • Page 8: Paddle Adjustment

    Paddle Adjustment All paddles can be adjusted to meet the size requirements of different people. By adjusting the two screws of the paddles, move the paddles outward or inward, and then tightened securely with the screws. Note: The operating torque of the bolts should not exceed 3Nm.
  • Page 9 SimBridge Plugin For Simhub XF1 Pro will be compatible with simhub through simbridge, enabling dashboard and LEDs customization. To use it, you need to place SimBridge in the Simhub installation directory and restart Simhub for it to take effect. Note: You can download the latest version on the website www.leoxz.com.
  • Page 10 Simhub Compatibility XF1 Pro is a plug-and-play device, so you can connect it to SimHub without having to complicatedly install any drivers. You can display various dashboards on screen and change brightness through SimHub, and you can also achieve various lighting effects by creating different profiles.
  • Page 11 Paddles Functionality The optional clutch paddles can be configured for axis mode and bite point mode. The optional option paddles can be configured for axis mode and button mode. All paddles have self-calibrate functionality to ensure high accuracy. This function requires that the paddles be pressed once (from minimum position to maximum position) each time the steering wheel is started.

  • Page 12: Quick Controls

    Quick Controls By binding any controller or keyboard input, you can quickly control the XF1 Pro dashboards switching, screen and LEDs brightness, clutch paddles and option paddles mode and bite point value. When changing the paddles mode, setting the bite point and LEDs brightness through...

  • Page 13: Firmware Update

    XF1 Pro and update the latest firmware. Once the update is completed, XF1 Pro will automatically restart. Note: You can download the latest firmware on the website www.leoxz.com. Do not operate the steering wheel during the update process, as it may cause unexpected errors.

  • Page 14: Hardware Reset

    Hardware Reset If the firmware update fails and the steering wheel cannot start normally, please try hardware reset to force the steering wheel to enter Bootload mode and update the firmware again. 1. Disconnect the power to the steering wheel to keep the steering wheel in a power-off state.
