Summary of Contents for BTSX BIT-Ma-ADI-0404
- Page 1 Shenzhen Bitvisus technology limited. Video News Co., Ltd Shenzhen Bitvisus technology limited. Video News Co., Ltd BIT-Ma-ADI-0404 Ultra HD Matrix Switcher 第 1 页 共 12 页...
-
Page 2: Table Of Contents
Shenzhen Bitvisus technology limited. Video News Co., Ltd CATALOG 1. Product Overview ..............3 1.1. Product features ..............3 1.2. Application scenarios ............3 2. Specifications ................4 3.Operation instructions .............. 6 3.1. Product panel description ..........6 4. Common problem ..............9 第... -
Page 3: Product Overview
Shenzhen Bitvisus technology limited. Video News Co., Ltd 1. Product Overview 1.1. Product features BIT-Ma-ADI-0404 is a 4 input 4 output all-digital ultra-clear matrix switcher, which supports a resolution of up to 4Kx2K,supports 3D video,HDCP1.4 specification,16 bit color depth.It can provide customers with a non-destructive, real-time,ultra-clear, full digital experience. -
Page 4: Specifications
11 ． Standard 1U industrial chassis, easy installation, fast operation, support 7X12 hours of uninterrupted work, support AC power in the range of 90-264V. 2. Specifications model BIT-Ma-ADI-0404 Specification Input / output support 4 channels each 第 4 页 共 12 页... - Page 5 Shenzhen Bitvisus technology limited. Video News Co., Ltd Input signal Full digital HDMI signal Output signal Full digital HDMI signal Control method RS-232、TCP/IP The highest resolution can reach 4k x 2k (4096 × Support resolution 2160) HDMI version HDMI 1.4 with 3D TV support Digital content protection Compatible with HDCP 1.4 Hot plug Plug and play, easy to install, support hot plug...
-
Page 6: Operation Instructions
Shenzhen Bitvisus technology limited. Video News Co., Ltd 3.Operation instructions 3.1. Product panel description （ 1 ） LCD screen ： It is used to display that the real-time operation status of control host to matrix and the keys. （ 2 ） POWER ： This is the indicator light of working power supply inside the chassis, which will be on after power on, indicating that the power supply is working normally. - Page 7 Shenzhen Bitvisus technology limited. Video News Co., Ltd all outputs SAVE Scene saving, using with number keys LOAD Scenario invoking, use with number keys CANCEL Cancel this operation ENTER Confirm operation Display format As shown in the figure, each two digits represents a channel, "in"...
- Page 8 Shenzhen Bitvisus technology limited. Video News Co., Ltd Example: Switch the third image signal to the fourth output, As follows: “3”+“AV” + “4”+“ENTER” (The following figure is LCD display) Ø One to all channel switching Example: Switch the second image signal to the all output As follows: “2”...
-
Page 9: Common Problem
Shenzhen Bitvisus technology limited. Video News Co., Ltd （1）HDMI input port （2）HDMI output port （3）Control interface RS232IN Serial port local control port, remote control of matrix. RS232LOO Local serial signal loop out port, used to forward matrix serial command. RJ45 TCP/IP Network control port, remote control of matrix. - Page 10 Shenzhen Bitvisus technology limited. Video News Co., Ltd broken or the connector is loose, just replace the connection cable; the HDMI cable is too long and no signal is input, you can replace the short cable. Check for signals at the corresponding outputs.(Use an oscilloscope or a multimeter for detection) If there is no signal output, the output connection cable may be broken or the connector is loose, just replace the connection cable;...
- Page 11 Shenzhen Bitvisus technology limited. Video News Co., Ltd software corresponds to the serial port of the connected device; check whether the communication port of the computer is good. Disclaimer： The illustrations and schematic diagrams involved in this manual are for reference only. For the appearance of the product, please refer to the actual product.
- Page 12 Shenzhen Bitvisus technology limited. Video News Co., Ltd 第 12 页 共 12 页...
