- Page 1 Shenzhen Bitvisus Technology Limited 深圳市比特视讯有限公司 BIT-Ma-ADI-0808 Ultra HD Matrix Switcher 第 1 页 共 9 页...
-
Page 2: Table Of Contents
Shenzhen Bitvisus Technology Limited CATALOG 1. Product Overview ......................3 1.1. Product features ..................... 3 1.2. Application scenarios .................... 3 2. Specifications ........................4 3.Operation instructions ....................5 3.1. Product panel description ................5 4. Common problem ......................8 第 2 页 共 9 页... -
Page 3: Product Overview
Shenzhen Bitvisus Technology Limited 1. Product Overview 1.1. Product features BIT-Ma-ADI-0808 is a 8 input 8 output all-digital ultra-clear matrix switcher, which supports a resolution of up to 4Kx2K,supports 3D video,HDCP1.4 specification,16 bit color depth.It can provide customers with a non-destructive, real-time,ultra-clear, full digital experience. -
Page 4: Specifications
8． Productfirmwarecanbeupgradedon-sitethroughthenetworkport,whichcanea silyprovideremotesupportonsiteandcustomizationofspecialfunctionsforusers. 9．Built-inequalizerupto100feetatinputand50feetatoutput. 10． Powerfulstoragefunction,canstoreandrecallmultiplepre-storedswitchingmo des;haspower-downmemoryfunction,withpower-offsiteprotectionfunction. 11．Standard1Uindustrialchassis,easyinstallation,fastoperation,support7X12ho ursofuninterruptedwork,supportACpowerintherangeof90-264V 2. Specifications model BIT-Ma-ADI-0808 Specification Input / output support 8 channels each Input signal Full digital HDMI signal Output signal Full digital HDMI signal Control method RS-232、TCP/IP The highest resolution can reach 4k x 2k (4096 ×... -
Page 5: Operation Instructions
Shenzhen Bitvisus Technology Limited Input / Output interface HDMI Interface Type A 19-pin Female type External power 110~220 VAC Storage and use temperature: -20 ° ~ + 70 ° Working environment humidity: 10% ~ 90% Product weight Rated power Chassis size (WxDxH) 1U（440mm x 263mm x 44mm）... - Page 6 Shenzhen Bitvisus Technology Limited STATUS：Blinks when the machine processes the command, and is normally on after processing. （3）Numeric key 0~9. （4）Function buttons. The function is briefly described as follows. Switch key, interval input and output Switch from optional input to all outputs SAVE Scene saving, using with number keys...
- Page 7 Shenzhen Bitvisus Technology Limited Ø One to one channel switching Example: Switch the third image signal to the fourth output, As follows: “3” + “AV” + “4” + “ENTER”(The following figure is LCD display) Ø One to all channel switching Example: Switch the second image signal to the all output As follows: “2”...
-
Page 8: Common Problem
Shenzhen Bitvisus Technology Limited （1）HDMI input port （2）HDMI output port （3）Control interface RS232IN Serial port local control port, remote control of matrix. RS232LOOP Local serial signal loop out port, used to forward matrix serial command. RJ45 TCP/IP Network control port, remote control of matrix. - Page 9 Shenzhen Bitvisus Technology Limited may be broken or the connector is loose, just replace the connection cable; the HDMI cable is too long and no signal is output, you can replace the short cable. When unplugging or inserting the video interface, you notice obvious static electricity: Check whether the external ground of the power supply of the device is well grounded, and ground it in the correct way, otherwise the host may be damaged.
