- Page 1 Shenzhen Bitvisus Technology Limited 深圳市比特视讯有限公司 BIT-Ma-GS-2.0-0404 Ultra HD Matrix Switcher 第 1 页 共 12 页...
-
Page 2: Table Of Contents
Shenzhen Bitvisus Technology Limited CATALOG 1. Product Overview ......................3 1.1. Product features ..................... 3 1.2. Application scenarios .................... 4 2. Specifications ........................5 3.Operation instructions ....................6 3.1. Product panel description ................6 3.2. Function description Remote control ............. 8 3.3.Device connection instructions ................ -
Page 3: Product Overview
Shenzhen Bitvisus Technology Limited 1. Product Overview BIT_Ma_GS_2.0_0404 is a 4-input 4-output all-digital ultra-clear matrix switcher, w hich can connect four HDMI signal sources to four displays at the same time, and can switch four HDMI signals easily and freely. It supports the highest resolution u 3840x2160@60, supporting video... -
Page 4: Application Scenarios
Shenzhen Bitvisus Technology Limited picture is clear. Supports 3D video. Supports audio formats: DTS-HD/Dolby trueHD/L PCM/DTS/Dolby-AC3/D The four outputs can display the same or different sources at the same tim Supports HDMI audio output, audio separation. Supports SPDIF audio. Supports panel button control and infrared remote control. With power-down memory function. -
Page 5: Specifications
Shenzhen Bitvisus Technology Limited 2. Specifications Name BIT-Ma-GS-2.0-0404 Ultra HD Matrix Switcher The highest Input resolution 3840*2160@60Hz Maximum bandwidth 18Gbps HDMI signal HDMI 2.0 x4 The highest output resolution of single screen 3840*2160@60Hz HDMI output interface HDMI 2.0 x4 Audio output HDMI、3.5mm Headphone holder... -
Page 6: Operation Instructions
Shenzhen Bitvisus Technology Limited 3.Operation instructions 3.1. Product panel description Front： A：3.5mm Headphone holder，Audio input，Can be connected to earphones and audio,etc. B：RCA socket, SPDIF audio output. C：IR, used to receive remote control signals. D： The OUT4 button and signal indicator are used for signal switching and showing input signal. - Page 7 Shenzhen Bitvisus Technology Limited fourth light on represents input 4. F：The button and signal indicator of OUT2 are used for signal switching and signal input signal display. From top to bottom, the first light on represents input 1, the second light on represents input 2, and the third light on represents input 3. The fourth light on represents input 4 G：...
-
Page 8: Function Description Remote Control
Shenzhen Bitvisus Technology Limited K ： 4 HDMI output ports for connecting display devices such as monitors, televisions or monitors. 3.2. Function description Remote control Remote control panel In the process of switching signals, you need to press [Enter] or [All] to take effect, and you can press [Cancel] to cancel when you need to cancel the parameter setting. -
Page 9: Device Connection Instructions
Shenzhen Bitvisus Technology Limited In1+Out3+ Enter：Output 3 is switched to the signal of input 1.。 In1+Out4+ Enter：Output 4 is switched to the signal of input 1. In2+Out1+ Enter：The output 1 is switched to the signal of the input 2. In2+Out2+ Enter：The output 2 is switched to the signal of the input 2. In2+Out3+ Enter：The output 3 is switched to the signal of the input 2. - Page 10 Shenzhen Bitvisus Technology Limited 1. Computers, Android boxes, game consoles and other devices are used as input sources and connected to the 4 input interfaces of BIT_Ma_GS_2.0_0404. 2. Connect the HDMI output port of BIT_Ma_GS_2.0_0404 to the display device. 3. The Audio output port of BIT_Ma_GS_2.0_0404 can be connected to headphones, audio and other equipment.BIT_Ma_GS_2.0_0404 接...
-
Page 11: Precautions
Shenzhen Bitvisus Technology Limited 4. Precautions 1. The equipment should be placed away from humidity, high temperature, corrosion and oxidation environment. 2. Do not touch the power adapter with wet hands. 3. 3. If you do not use the device for a long time, please turn off the power. 4. - Page 12 Shenzhen Bitvisus Technology Limited the device motherboard interface; if there is no output signal due to hot plugging of the HDMI cable, please switch the device to return to normal. 第 12 页 共 12 页...
