- Page 1 OPERATING MANUAL P U B L I C A D D R E S S P O W E R AMPLIFIER PA-9336...
-
Page 2: Unpacking And Installation
UNPACKING AND INSTALLATION Although it is neither complicated to install nor difficult to operate your PA amplifier, a few minutes of your time is required to read this manual for a properly wired installation and becoming familiar with its many features and how to use them. Please take a great care in unpacking your amplifier and do not discard the carton and other packing materials. - Page 3 FEATURES • THERMAL PROTECTION & AUTOMATIC IDLING CIRCUITRY To insure stability and reliability against over-current and over-heating, thermal protection circuitry is provided. In addition, automatic idling circuit is provided to protect against thermal run-away. • BALANCED INPUT A balanced input is provided to reduce hum picked up from a long distance input cable and to avoid ground loop problem when you build the system.
-
Page 4: Front Panel Controls
FRONT PANEL CONTROLS PA-9336 PUBLIC ADDRESS POWER AMPLIFIER 1. POWER INDICATING LED This LED indicates power is turned ON. 2. POWER SWITCH Pressing this switch to ON will make the power indicating LED ON and supply the power to unit. -
Page 5: Rear Panel Controls
4. FUSE HOLDERS These fuse holders contain AC. Replace them with the same type fuse when they are blown out. If they continuously blow, stop replacing fuses and refer servicing to qualified personnel. MODEL NO;PA-9336 PUBLIC ADDRESS POWER AMPLIFIER OUTPUT POWER:360W... - Page 6 5. AC INLET This terminal is connected AC input cord. 6. HIGH-PASS FILTER SWITCH This switch is for activating the High-pass Filter circuit, to protect speakers from excessive low frequency power demands. The –3dB frequency of the High-pass Filter is 400Hz. 7.
- Page 7 SWED 2 (2000W) SWED 3 (2000W) PB-9207A AC INPUT: 220V,60Hz 139VA FUSE: 1A/250V DC INPUT CHIME MIXER LINE OUT TUNER DECK PHONO MODEL NO;PA-9336 PUBLIC ADDRESS POWER AMPLIFIER OUTPUT POWER:360W MADE IN KOREA BALANCED INPUT LINK 1V/10KΩ INPUT(ADJ) GROUND LIFT...
-
Page 8: Specifications
SPECIFICATIONS ELECTRICAL Rated output (THD 1%) ...360W (RMS) Input Sensitivity/Impedance ...1V/10KΩ, BAL T.H.D (at 1KHz, Rated Output) ...Less than 1% Frequency Response (+1/–3dB) ...70Hz~20KHz S/N...Better than 95dB H.P.F ...–3dB at 400Hz Input Level Adjustment ...–12dB~0dB GENERAL Power Source ...AC 110V~240V, 50Hz/60Hz, DC 24V Weight (Net) ...21Kg Dimensions ...482(W) 132(H) 280(D)mm Specifications and design subject to change without notice for improvements. - Page 9 MADE IN KOREA...
