Residential TouchScreen Programmable Thermostats
PSP4272RT
PSP4273RT
1 Specifications 2 Glossary of Terms 3 About Your Thermostat
4 Quick Start 5 Main Menu Buttons 6 Installation Instructions
7 Troubleshooting 8 Warranty
WARNING
CAUTION
Follow Installation Instructions carefully. Disconnect Power to the
Heater/Air Conditioner before removing the old thermostat and
installing the new thermostat.
1 Specifications
model PSP4272RT
•
Up to 4 Heat & 2 Cool Stages
•
Gas Electric or Heat Pump Control
•
Dual Fuel Capable
•
Simple as you want Operation
•
Switchable Programmable or
Non-Programmable
• Adjustable Timers & Deadbands
•
Setpoint Limiting
•
Accepts Remote Sensor or Outdoor Sensor
•
Choice of English, Spanish or French
•
Customizable Screensaver & Wallpaper
•
CA Title 24 Compliant
•
Wi-Fi Built In Free mobile apps available
•
OEM-branded Equipment Badges Included
Up to 4-heat / 2-cool
Up to 4-heat / 2-cool with Humidity Control
User & Installer
model PSP4273RT
•
Up to 4 Heat & 2 Cool Stages
•
Gas Electric or Heat Pump Control
•
Dual Fuel Capable
•
Switchable Programmable or Non-
Programmable
•
Adjustable Timers & Deadbands
•
Setpoint Limiting
•
Equipped with Humidity Sensor: Controls
Humidification & Dehumidification
•
Accepts Remote Sensor or Outdoor Sensor
•
Choice of English, Spanish, or French
•
Customizable Screensaver & Wallpaper
•
CA Title 24 Compliant
•
Wi-Fi Built In Free mobile apps available
•
OEM-branded Equipment Badges Included
© Copyright 2021, All Rights Reserved
Manual
Advertisement
Table of Contents
Related Manuals for PROSTAT+ OEM Series
Summary of Contents for PROSTAT+ OEM Series
- Page 1 User & Installer Manual Residential TouchScreen Programmable Thermostats PSP4272RT Up to 4-heat / 2-cool PSP4273RT Up to 4-heat / 2-cool with Humidity Control 1 Specifications 2 Glossary of Terms 3 About Your Thermostat 4 Quick Start 5 Main Menu Buttons 6 Installation Instructions 7 Troubleshooting 8 Warranty WARNING CAUTION...
-
Page 2: Table Of Contents
Table of Contents 3 Get To Know Your Thermostat Home Screen ..............1 Menu Screens ..............1 Dropdown Dashboard ...........2 Care and Use of Your Thermostat ........5 4 Quick Start Selecting Your Desired Temperature and Mode ....6 Using the Fan Button.............6 Setting the Time & Date ..........7 Setting the Time ............8 Setting the Date ............9 Daylight Savings Setup ..........9... - Page 3 Alerts .................20 View Current Alerts .............21 Reset Alerts ..............21 Set/Edit Reminders .............21 Service Information (Who To Call For Service)....21 Display ..............22 Active Brightness ............23 Idle Brightness ............23 Night Dimmer .............23 Maintenance ...............24 Preferences ...............25 User Interface Themes ..........26 Custom Wallpaper ............26 Heat/Cool Indicator .............26 Sound Options ............26 Humidity ..............27...
- Page 4 Settings ..............36 Thermostat Name ............40 Available Modes ............40 SD Card (Import and Export) ........40 General Setup ............40 Units (F or C) ...............40 Language ..............41 Smart Recovery On/Off ..........41 Simple Thermostat On/Off ...........41 AUTOMATED DEMAND RESPONSE ......42 Installation Settings ..........56 Heat & Cool Stages .............56 Heat &...
- Page 5 Wired Sensor Use ............61 Calibrate Sensors............62 Test Outputs ...............62 Dealer Information ............63 Upgrade Firmware ............63 Delete Custom Images ..........63 Reset to Factory Default Settings ........63 Restart Thermostat .............63 Wi-Fi ................64 Enabled ..............65 Status .................65 Setup ................65 Local API ..............65 SKYPORT ..............69 Account ..............69 Emergency Heat ............70 6 Installation Instructions...
- Page 6 CAUTION Follow the Installation Instructions before proceeding. Set the thermostat mode to “OFF” prior to changing settings in setup or restoring Factory Defaults. FCC Compliance Statement This equipment has been tested and found to comply with the limits for an intentional radiator, pursuant to Part 15, subpart C of the FCC rules.
- Page 7 Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a type and maximum (or lesser) gain approved for the transmitter by Industry Canada. To reduce potential radio interference to other users, the antenna type and its gain should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that necessary for successful communication.
- Page 8 2 Glossary of Terms Auto-Changeover: A mode in which the thermostat will turn on the heating or cooling based on room temperature demand. Cool Setpoint: The warmest temperature that the space should rise to before cooling is turned on (without regard to deadband). Deadband: The number of degrees the thermostat will wait, once a setpoint has been reached, before energizing heating or cooling.
-
Page 9: Get To Know Your Thermostat
3 Get to Know Your Thermostat Backlit TouchScreen Display Indoor Humidity Reading (PSP4273RT ONLY) HOME SCREEN Outdoor Temperature Drop Down Dashboard Connectivity Symbol Date & Time Button Connectivity Symbol Table Not connected SD Card Slot to Wi-Fi Warmer Connected to local access point w/IP Fan Button &... -
Page 10: Dropdown Dashboard
Get To Know Your Thermostat Dropdown Dashboard (The contents of your Dashboard may vary) The Dropdown Dashboard displays temperature, humidity, and other readings. It will also show the high and low readings of the day. Connectivity Symbol Table Wi-Fi Wi-Fi Drop Down Drop Down Connection... - Page 11 Get To Know Your Thermostat Equipment Runtimes This screen allows you to view daily heating and cooling runtimes and can show details about which stages were active. To view one week of runtime data, press menu > information > view runtime graphs Weather This screen only appears when...
- Page 12 Get To Know Your Thermostat Alerts This screen shows some information about any active alerts. More information about alerts as well as resetting active alerts can be found at menu > alerts. Thermostat Information PSP4273RT Residential This section contains four different screens that allow easy viewing of the thermostat model number, firmware revision, wifi...
-
Page 13: Care And Use Of Your Thermostat
Get To Know Your Thermostat Care and Use of Your Thermostat Pencils, pens and other sharp objects should never be used on your thermostat; these may damage your touchscreen. Only use your finger tip to press the touchscreen buttons. Use a soft, damp cloth to clean the screen. DO NOT USE ABRASIVE CLEANERS OR CLEANERS THAT CONTAIN SOLVENTS. -
Page 14: Quick Start
4 Quick Start - Temperature, Modes & Fan Selecting Your Desired Temperature and Mode Press to adjust temperature Cool Setpoint The Heat or Cool Setpoint is Warmer Button the temperature the room has to reach before heating or cooling will turn on. (Without regard Cooler Button... -
Page 15: Setting The Time & Date
Set Time & Date NOTE: When the thermostat is connected to a Skyport account, the Time & Date are automatically synchronized to the Skyport Cloud, including automatic Daylight Savings adjustments. Your time zone is selected in the Skyport web application. Set Time &... -
Page 16: Setting The Time
Setting the Time Press then to scroll down. MENU Press Set Time & Date Press Set Current Time (12:00 AM) hr + min + Press to set the current time. hr - min - Press when finished. BACK Choose Use AM/PM - ON For 12 hour AM/PM clock Use AM/PM - OFF For 24 hour clock... -
Page 17: Setting The Date
Setting the Date Press Set Current Date 12/1/2020 Press to set the current month and year. Press the day on the calendar Press BACK when finished. Daylight Savings Setup Turn Daylight Savings Daylight Savings Time - OFF Time on or off. Daylight Savings Time - ON Adjust when Daylight Start Schedule... -
Page 18: Connecting To Wi-Fi
Connect to Wi-Fi (from initial start up) When power is connected to the thermostat and it has not been configured to connect to a Wi-Fi Access point, the following message appears: Wi-Fi Set Up No Wi-Fi access points are configured for your thermostat. Would you like to set up one now? Press YES Select the access point you wish to connect to from the list. - Page 19 Quick Start - Connect to Wi-Fi (from menus) MENU Press MENU Press DOWN Press Wi-Fi Press Wi-Fi Setup • Wi Fi Setup Select the access point from the list that you want to connect to. Enter the password for the Wi-Fi Access Point and press NEXT. Select automatic setup and press NEXT.
-
Page 20: Wi-Fi Set Up - Create A Skyport Account
Quick Start - Connect to Wi-Fi (from menus) Although there is more than one way to create a Skyport account, the steps below illustrate creation from the mobile app. If the thermostat is connected to the local Wi-Fi Access Point, but not yet joined to a Skyport account, you may join the thermostat to an account by doing the following: Select MENU from the thermostat’s home screen. -
Page 21: Main Menu Buttons Schedule
5 Main Menu Buttons - Schedule Schedule View My Schedule Edit My Schedule Manual & Installer Guide... -
Page 22: View My Schedule
Main Menu Buttons – Schedule This thermostat features up to four programmable time periods per 24 hour day: Morning, Day, Evening, and Night. The start time for each time period is adjustable. The stop time for each time period is Schedule the start time for the next period. - Page 23 Main Menu Buttons – Schedule Edit My Schedule (Continued) Press and select a Time Period (Morning, Day, Evening, or Night) to edit. Next Adjust Mode, Start Time, and Heat and Cool Setpoints to desired settings. The Time Period may also be Enabled or Disabled. Un-check the Enabled box for Time Periods you don’t want to use.
-
Page 24: Smart Fan
Main Menu Buttons – Smart Fan Smart Fan Smart Fan - OFF Who To Call For Service Smart Fan Min Runtime View Runtime Graphs Start/Stop Times Who To Call For Service Days To Run Fan View Runtime Graphs Manual & Installer Guide... -
Page 25: Smart Fan On/Off
Main Menu Buttons – Smart Fan The fan may be programmed to turn on automatically for a specified period during the day. Smart Fan Press to turn fan schedule on or off Smart Fan - OFF Smart Fan - ON Smart Fan Min Runtime (10m) Set the minimum number of minutes the fan will run from the top... -
Page 26: Screensaver
Main Menu Buttons – Screensaver Screensaver Screensaver - OFF Who To Call For Service Screensaver Setup View Runtime Graphs Screensaver Turn On Delay Screensaver Type Slideshow Digital Clock Analog Clock Change Image After... Use Theme Images - OFF Randomize Slideshow - OFF Show Clock - OFF Home Screen Info - OFF Screensaver Preview... -
Page 27: Screensaver Setup
Main Menu Buttons – Screensaver The Screensaver allows you to create custom slideshows. Screensaver Screensaver - OFF Screensaver - ON Screensaver Setup Screensaver Turn On Delay (5m) How long after a button press for the Screensaver to appear. 1, 3, 5, or 30 minutes Screensaver Type (Slideshow) Slideshow, Digital Clock, Analog Clock... -
Page 28: Alerts
Main Menu Buttons – Alerts Alerts View Current Alerts Reset Alerts Reset Air Filter Alert Reset UV Lamp Alert Reset Humidity Pad Alert Set/Edit Reminders Service Call Reminder - OFF Days Until Service Call (0 days) Air Filter Reminder - OFF Set Max Filter Runtime (300 hrs) Set Max Filter Days... -
Page 29: View Current Alerts
Main Menu Buttons – Alerts The alerts let you know when your system needs service. Alerts View Current Alerts View and reset current Alerts will appear service alerts here. on the bottom bar of the Home Screen. Press to view and reset current alerts. -
Page 30: Display
Main Menu Buttons – Display Display Active Brightness Idle Brightness Night Dimmer Auto Night Dimmer - OFF Set Idle Brightness Set Dimmer Schedule Maintenance Screen Cleaning Touch Calibration Manual & Installer Guide... -
Page 31: Active Brightness
Main Menu Buttons – Display The display brightness options may be adjusted in this menu. Display Active Brightness (80%) You may select how bright the backlight is while the thermostat is active. The display is active for 3 minutes after last touch, it then goes Idle. Idle Brightness (30%) You may select how bright the backlight is while the thermostat is idle. -
Page 32: Maintenance
Main Menu Buttons – Display Maintenance Maintenance allows you to clean and calibrate the touch screen. Screen Cleaning Screen Cleaning Mode disables the touch feature for 15 seconds so the screen may be cleaned without altering any settings. Use a soft cloth without solvents or abrasive cleaners Touch Calibration Under normal circumstances, the touchscreen should not need to be calibrated. -
Page 33: Preferences
Main Menu Buttons – Preferences Preferences User Interface Themes Custom Wallpaper Heat/Cool Indicator Heat/Cool Indicator OFF Taskbar red/white OFF Room Temp red/blue OFF Mode Status red/blue OFF Sound Options Beep - OFF Beep Sound Manual & Installer Guide... -
Page 34: User Interface Themes
Main Menu Buttons – Preferences You may set the type of background that appears on the thermostat Preferences Home Screen. User Interface Themes (ocean) This thermostat has several high quality background themes to choose from. NOTE: At 7pm, the background will change to an evening scene. At 7am it will return to a daytime scene. -
Page 35: Humidity
Main Menu Buttons – Humidity This section only applies to the PSP4273RT thermostat Humidity Humidification Settings Humidify setpoint (0%) Humidify with heat - OFF Run fan w/humidity demand - OFF Dehumidification Settings Dehumidity setpoint (99%) Run A/C to dehumidify - OFF Maximum Overcool (0°) Reheat - OFF... -
Page 36: Humidification Settings
Main Menu Buttons – Humidity This section only applies to the PSP4273RT thermostat The Humidity feature allows the thermostat to control a humidifier or use your air conditioner to dehumidify the space. Humidity IMPORTANT: Aux Output Usage must be set for Hum or Dehum for these settings to take effect. -
Page 37: Vacation/Away
Main Menu Buttons – Vacation / Away Vacation/Away Clear Vacation Schedule Set Vacation Schedule Start Date Start Time Return Date Return Time Settings while away Mode Auto Heat Cool Heat Setpoint Cool Setpoint Manual & Installer Guide... -
Page 38: Clear Vacation Schedule
Main Menu Buttons – Vacation / Away Vacation or pressing the AWAY button, will use temporary, energy saving settings without changing the regular schedule. Pressing the HOME button will return the thermostat to Vacation/Away normal comfort settings. Clear Vacation Schedule Removes the stored vacation schedule. -
Page 39: Schedule
Main Menu Buttons – Vacation / Away Set Vacation Schedule (Continued) Return Date Tue Dec 21 2020 Select the day Vacation Mode SEPTEMBER 2020 will end. Then press BACK BACK Return Time (3:00 PM) Select the time Vacation Mode will end. Then press BACK Settings while away... -
Page 40: Security
Main Menu Buttons – Security Security Auto Screenlock Auto Screenlock - OFF Set Passcode Lock After... Allow fan/mode changes - NO Allow setpoint changes - NO Allow Home/Away changes - NO Setpoint Limits Setpoint Limits - OFF Minimum Cool Setpoint Maximum Heat Setpoint Manual &... -
Page 41: Auto Screenlock
Main Menu Buttons – Security Security settings may be set to limit or prevent changes to your thermostat. Security Auto Screenlock NOTE: Code must be set Auto Screenlock - OFF before Auto Screenlock can be turned on. Auto Screenlock - ON Set Passcode (code not set ) Use keypad to enter and confirm passcode. -
Page 42: Information
Main Menu Buttons – Information Information View Runtime Graphs Last 7 Days - Cooling Last 7 Days - Heating Delete Runtime Data Who To Call For Service Manual & Installer Guide... -
Page 43: View Runtime Graphs
Main Menu Buttons – Information This button contains valuable service and system runtime information. Information View Runtime Graphs Track your system’s runtime/energy usage. Last 7 Days - Cooling Press the information icon to learn more about each graph *NOTE: The runtime graphs are updated Last 7 Days - Heating at 12:00 AM each day. -
Page 44: Settings
Main Menu Buttons – Settings Settings Thermostat Name Available Modes All Modes Including Auto Heat and Cool Heat Only Cool Only SD Card Import Settings from SD Card Export Settings to SD Card General Setup Units Fahrenheit Celsius Language English Spanish/Espanol French/Francais Smart Recovery - ON/OFF... - Page 45 Main Menu Buttons – Settings Settings (Continued) Installation Settings Timers & Deadbands Cycles Per Hour Min Heat/Cool Difference Compressor Min Off Time 1st Stage Deadband 2nd Stage Deadband 2nd Stage Deadband 2nd Stage Timer 2nd Stage Turnoff Point Deadband Setpoint 3rd Stage Deadband 3rd Stage Deadband 3rd Stage Timer...
- Page 46 Main Menu Buttons – Settings Settings (Continued) Installation Settings Heat Pump Settings Heat Pump Lockout - Enabled/Disabled HP Lockout Outdoor Temp Aux Heat Lockout - Enabled/Disabled Aux Heat Lockout Temp Dual Fuel Settings Dual Fuel - On/Off Changeover With Outdoor - On/Off Adjust Balance Point PSP4273RT Only AUX Output Settings...
- Page 47 Main Menu Buttons – Settings Settings (Continued) Installation Settings Test Outputs Dealer Information Dealer Name Contact Name Dealer Phone Dealer Email Dealer Website Upgrade Firmware Delete Custom Images Factory Defaults Restart Thermostat Manual & Installer Guide...
-
Page 48: Thermostat Name
Main Menu Buttons – Settings Thermostat heating and cooling options are found in this menu Settings Thermostat Name Use keypad to name your thermostat. The name is displayed on the Home Screen. (Up to 14 characters) Name appears here Available Modes (all) Choose the desired modes the thermostat will use: Heat, Cool, Heat &... -
Page 49: Language
Main Menu Buttons – Settings General Setup (Continued) Language (en) English Spanish/Español French/Français Smart Recovery - OFF Smart Recovery - ON Smart Recovery turns on the heat or cool before the Morning start time to bring the room temperature to the Morning setpoint at the start of the Morning time period. -
Page 50: Automated Demand Response
Main Menu Buttons – Settings Automated Demand Response OVERVIEW TouchScreen thermostats support the handling of specific signals from the utility provider. The utility generated signals carry pricing information and/or setback actions that alter the comfort settings of the thermostat in order to reduce energy usage on demand. - Page 51 Main Menu Buttons – Settings The Demand Response configuration page, shown below, is where the thermostat is configured to respond to the energy provider’s signals. It also sets operational parameters for the thermostat. The left column of the ADR configuration page allows or prevents access by the utility.
- Page 52 Main Menu Buttons – Settings The right column of the ADR configuration page is where the occupant adjusts the operational parameters for ADR. The utility may send up to 3 types of ADR signals to Skyport. These are: 1) Pricing for the cost of energy, 2) An Offset to the occupants’ comfort setpoints, and 3) a signal to enforce discrete or Static setpoints.
- Page 53 Main Menu Buttons – Settings Selecting the Overview tab of the ADR page will cause a summary of ADR events to be displayed. Manual & Installer Guide...
- Page 54 Main Menu Buttons – Settings Automated Demand Response Utility and Program setup must be done at the Skyport Cloud Services account. From the thermostat Home Screen, press the ‘Menu’ button, then select ‘Settings”. From the above screen the ‘Automated Demand Response’ button is pressed. By selecting ADR –...
- Page 55 Main Menu Buttons – Settings Selecting the ‘Price Dependent Action’ button allows the user to determine what action is taken when the price rises above the set threshold. In the above example; if the price threshold is exceeded, the thermostat will invoke the ‘Offset Setpoints’...
- Page 56 Main Menu Buttons – Settings The user may limit the maximum Cooling Setpoint. Manual & Installer Guide...
- Page 57 Main Menu Buttons – Settings The user may limit the minimum Heating Setpoint. Manual & Installer Guide...
- Page 58 Main Menu Buttons – Settings The user may adjust the ADR Cooling ‘static’ Setpoint. Manual & Installer Guide...
- Page 59 Main Menu Buttons – Settings The user may adjust the ADR Heating ‘static’ Setpoint. Manual & Installer Guide...
- Page 60 Main Menu Buttons – Settings The user may adjust the ADR Cool offset. During an ADR event the cooling setpoint will be adjusted by the amount of degrees configured in this step. Manual & Installer Guide...
- Page 61 Main Menu Buttons – Settings The user may adjust the ADR Heat offset. During an ADR event the heating setpoint will be adjusted by the amount of degrees configured in this step. Manual & Installer Guide...
- Page 62 Main Menu Buttons – Settings When an ADR event is pending, and hasn’t started yet, there will be a yellow leaf on the top bar. This will be accompanied by associated text as shown below. During an ADR event there will be a green leaf on the top bar. This will be accompanied by associated text as shown below.
- Page 63 Main Menu Buttons – Settings If a Warmer or Cooler button is pressed during an active ADR event, then the user is presented with this opt-out screen. If a pricing triggered ADR event is enabled, there will be a green leaf on the top bar along with the actual cost of energy.
-
Page 64: Installation Settings
Main Menu Buttons – Settings Installation Settings Heat & Cool Stages (1h1c) Heat & Cool Stages (1h1c) Up to 2 Stages Cooling and 4 stages Heating. Compressor Stages (1h1c) Only available when Up to 2 compressors. dip switch is set for Heat Pump operation. -
Page 65: Timers & Deadbands
Main Menu Buttons – Settings Installation Settings (Continued) Timers & Deadbands (Continued) The Deadband is the number of degrees or minutes that the thermostat waits before it initiates the stages of heating or cooling. 1st Stage Deadband Specifies the minimum temperature difference between the room temperature and the desired setpoint before the first stage of heating or cooling is allowed to turn on. -
Page 66: Free Cooling
Main Menu Buttons – Settings (Continued) Installation Settings Free Cooling Free Cooling requires additional dampers and duct work to be installed. Additionally, the thermostat is wired in a different manner for this feature to function properly. Before enabling this feature, please make sure these steps are completed. Free Cooling - DISABLED Free Cooling - ENABLED Turns on Free Cooling. -
Page 67: Heat Pump Settings
Main Menu Buttons – Settings Installation Settings (Continued) (Only available Heat Pump Settings when dip switch is set for Heat Pump operation.) Heat Pump Lockout - DISABLED Heat Pump Lockout - ENABLED Turns on Heat Pump Lockout. HP Lockout Outdoor Temp (65˚) Heat Pump will not run below this temp. -
Page 68: Aux Output Settings
Main Menu Buttons – Settings (Continued) • Installation Settings This section only applies to the PSP4273RT thermostat (Continued) Installation Settings AUX Output Settings Allows the W3/AUX output to be used for Heating, Humidification, or Dehumidification. AUX output usage (W3) IMPORTANT: Aux Output Usage must be set for Hum or Dehum before any settings will take effect in the Humidity Main Menu. -
Page 69: Fan Off Delay
Main Menu Buttons – Settings (Continued) Installation Settings Fan Off Delay (0s) Runs the fan for a short time after Cooling or electric strip heat turns off to increase system efficiency. (0 - 120 Secs.) Sensor Settings Control Source (thermostat ) The thermostat allows multiple wired or wireless sensor accessories to be connected/paired to the thermostat. -
Page 70: Wired Sensor
Main Menu Buttons – Settings (Continued) Installation Settings Wired Sensor Use (remote) The wired sensor may be used as follows: • Use as outdoor sensor • Use as remote sensor • Use as supply sensor • Use as return sensor Calibrate Sensors (0˚) The thermostat and wired sensor may be calibrated -7 to +7 degrees F . -
Page 71: Dealer Information
Main Menu Buttons – Settings Dealer Information A Dealer may enter their company contact information for the customer to use when they need service. This will appear when the “Who To Call For Service” button is pressed in the Information Menu. Use the keyboard to enter your information. -
Page 72: Wi-Fi
Main Menu Buttons – Wi-Fi Wi-Fi Enabled Wi-Fi Status Wi-Fi Setup Choose Network Password Entry Local API Option Local API - OFF API Protocol HTTP HTTPS Manual & Installer Guide... -
Page 73: Enabled
Main Menu Buttons – Wi-Fi Wi-Fi Wi-Fi Enabled This option allows the Wi-Fi radio to be turned off or on. Wi-Fi Status It is here that you will find helpful information regarding the connectivity status of your thermostat, including the thermostat’s ID. Wi-Fi Setup Choose your network from the list and enter... - Page 74 Main Menu Buttons – Wi-Fi This is the default with the local API OFF. • Local API - OFF • API Protocol (http) To turn on the HTTP Local API select Local API • Local API - ON • API Protocol (http) Press BACK to return to previous screen.
- Page 75 Main Menu Buttons – Wi-Fi Upon pressing BACK, the screen will look like this. • Local API - OFF • API Protocol API Protocol (https) (http) • Basic Auth User PRESS • Basic Auth Password API Protocol (http) • Basic Auth User Select Basic Auth User, and enter (64 remaining) the appropriate information on the...
- Page 76 Main Menu Buttons – Wi-Fi • Basic Auth Password Select Basic Auth Password and (64 remaining) enter the appropriate information on the screen below and press DONE to save. Shift 123!? SPACE BACK Basic Auth Password DONE The last step is to turn the Local API as shown below. •...
-
Page 77: Skyport
Main Menu Buttons – Skyport Skyport Skyport Services - ON Weather Updates - ON Skyport Account Skyport Account Pressing this button will let you know if you are paired with a Skyport account. If not, then you may follow prompt and instructions to create an account and add the thermostat to the account. -
Page 78: Emergency Heat
Main Menu Buttons – Emergency Heat The Emergency Heat function is only available if your thermostat is set to control a Heat Pump. Emergency Heat To initiate the Emergency Heat feature, Press the Emergency Heat button. During Emergency Heat operation the thermostat will turn on the fan and auxiliary stages of heat when there is a demand for heat. -
Page 79: Installation Instructions
6 Installation Instructions Remove and Replace the old thermostat To install the thermostat properly, please follow these step by step instructions. If you are unsure about any of these steps, call a qualified technician for assistance. • Assemble tools: Flat blade screwdriver, wire cutters and wire strippers. •... -
Page 80: Wire Connections
Installation Instructions – Wire Connections If the terminal designations on your old thermostat do not match those on the new thermostat, refer to the chart below or the wiring diagrams that follow. Wire from the Install on the old thermostat Function new thermostat terminal marked... -
Page 81: Determining Your Existing Wiring And Equipment
Installation Instructions – Wire Connections Before you go any further, determine what your existing wiring and equipment situation is. If you have a Heating only system without Air Conditioning, the ProStat+ thermostat will require 3 wires: R (24Vac), C (24Vac) and W (Heat). Most systems that only have Heating use very simple thermostats that require 2 wires: the R (24Vac) and W (Heat). - Page 82 Installation Instructions – Wire Connections If you have a heat pump without aux heat, the ProStat+ model will require 5 wires: R (24Vac), C (24Vac), W1/O/B (Reversing Value), Y (1 Stage Compressor), and G (Fan). If you are short 1 wire, there are at least 3 options available to connect the ProStat+ thermostat: 1.
-
Page 83: Making 4 Wires Work When 5 Wires Are Required
Installation Instructions – Wire Connections Making 4 Wires Work When 5 Wires Are Required If you would like to install the ProStat+ thermostat using only 4 wires when 5 are required, follow the directions below. You will need a screwdriver along with a 3" long piece of thermostat wire to use as a jumper: 1. -
Page 84: Making 5 Wires Work When 6 Wires Are Required
Installation Instructions – Wire Connections Making 5 Wires Work When 6 Wires Are Required If you have a system that requires 6 wires, and you would like to install the ProStat+ thermostat using only 5 wires, follow the directions below. You will need a screwdriver along with a 3"... -
Page 85: The Touchscreen Thermostat Backplate
Installation Instructions – Thermostat Backplate NOTE: The backplate does not fully cover a full size vertical junction box. The PSPAC-WPT ProStat+ Wallplate or a single-gang, horizontally mounted junction box would be needed for that SENSOR type of installation To remove the thermostat backplate: Front Housing Using the Finger Pull Areas, pull the front Backplate... -
Page 86: Explanation Of The Thermostat Dip Switches
Installation Instructions – Dip Switches Explanation of Thermostat Dip Switches Dip switches are located on the back of the thermostat GAS/EL ELEC SENSOR This dip switch configures the thermostat to control a GAS/EL GAS/EL conventional gas/electric system or a heat pump. If your system is anything other than a heat pump, leave this switch set for GAS/EL.* *For some commercial heat pumps, this switch may need to be... -
Page 87: Sample Wiring Diagrams
Installation Instructions – Sample Wiring Diagrams Sample Wiring Diagrams with Dip Switch Positions Conventional Heating and Cooling Systems 2 Wire, Heat Only 3 Wire, Heat Only Residential & Commercial 1 Stage Heating Residential & Commercial 1 Stage Heating with no Fan. with no Fan. - Page 88 Installation Instructions – Sample Wiring Diagrams Sample Wiring Diagrams with Dip Switch Positions Heat Pump Systems 5 Wire, 1 Stage Cooling, 1 Stage Heat 6 Wire, 1 Stage Cooling, 2 Stage Heat Residential & Commercial Heat Pump with Residential & Commercial Heat Pump with ‘O’...
- Page 89 Installation Instructions – Sample Wiring Diagrams Sample Wiring Diagrams with Dip Switch Positions Heat Pump Systems with Dual Fuel 7 Wire, 2 Stage Cooling, 3 Stage Heat Residential & Commercial Heat Pump with ‘O’ Reversing Valve and Fossil Fuel furnace. 24VAC Power GAS/EL 24VAC Common...
- Page 90 Installation Instructions – Sample Wiring Diagrams Outdoor Sensor: PSPAC-OS Temperature Sensor 10K ohm sensor at 77F/25C. Negative Temperature Coefficient. Use 18-22 gauge thermostat wire. 10K Thermistor SENSOR Outdoor Sensor PSPAC-OS Use 18-22 gauge thermostat wire. 10K Thermistor SENSOR Remote Sensor Manual &...
- Page 91 Installation Instructions – Sample Wiring Diagrams This section only applies to the PSP4273RT thermostat Humidification Use 16-24 gauge AUX Output Usage thermostat wire. must be set for Hum SENSOR Humidification System Dehumidification AUX Output Usage must be set for Dehum Use 16-24 gauge thermostat wire.
-
Page 92: Troubleshooting
7 Troubleshooting • SYMPTOM: The thermostat touchscreen buttons are not responsive. CAUSE: The touchscreen is out of calibration. REMEDY: Remove the thermostat from the backplate. Push the thermostat back onto the backplate, while keeping your finger pressed firmly against the center of the touchscreen, until the Calibration screen appears. -
Page 93: Warranty
8 Limited Warranty PSP Series - Thermostat Models: PSP1100, PSP1152, PSP2100, PSP2152, PSP2270, PSP2270C, PSP2111, PSP4272, PSP4273, PSP4271C, PSP4272C, PSP4272RT, PSP4273RT, PSP4272CT, PSP4273CT Who Is Providing The Warranty? For further information about this warranty contact This warranty is provided to you by Goodman Consumer Affairs at (877) 254-4729 or by mail to 19001 Manufacturing Company, L.P. - Page 94 NOT LIMITED TO LOST PROFITS, LOSS OF USE OF A (3) For products on which a manufacture date is CONTROL, EXTRA UTILITY EXPENSES, OR DAMAGES indicated, if the date the owner purchases the TO PROPERTY. residence from the builder or the date the product is originally installed cannot be verified, the installation Some states and provinces do not allow the exclusion or date is three months after the manufacture date.
- Page 95 or controversy arising from or relating to your purchase org), JAMS (1920 Main Street, Ste. 300, Irvine, CA of this control, any warranty upon the unit, or the unit’s 92614, www.jamsadr. com), or, subject to our approval, condition. It also includes determination of the scope or any other arbitration organization.
- Page 96 Battery Stat Tested to Comply with FCC Standards FOR HOME OR OFFICE USE 4Z95 Patents Issued & Pending P/N 88-1432 Rev. 2 04/23/21...
