- Page 1 OPERATING MANUAL - BA03.22 Hydrocont HP4SC Hydrostatic filling level transmitter with capacitive ceramic measuring membrane...
-
Page 2: Table Of Contents
Signal processing ..................................15 Y O U R P A R T N E R F O R M E A S U R E M E N T & A U T O M A T I O N www.acs-controlsystem.com... -
Page 3: Safety Instructions
The device meets the legal requirements of all relevant EU directives. This is confirmed by attaching the CE mark. The associated EU-Declaration of Conformity can be ordered or downloaded from the homepage. ACS-CONTROL-SYSTEM GmbH | Lauterbachstr. 57 | 84307 Eggenfelden | Germany info@acs-controlsystem.de | +49 (0) 8721/9668-0... -
Page 4: Product Description
Factory calibration – calibration certificate Y O U R P A R T N E R F O R M E A S U R E M E N T & A U T O M A T I O N www.acs-controlsystem.com... -
Page 5: Function
Not exposed to corrosive media • • Protected against solar radiation • Avoiding mechanical shock and vibration • Storage and transport temperature -20…+85°C Relative humidity 20…85% • ACS-CONTROL-SYSTEM GmbH | Lauterbachstr. 57 | 84307 Eggenfelden | Germany info@acs-controlsystem.de | +49 (0) 8721/9668-0... -
Page 6: Installation
WARNING: Let the system cool down sufficiently before installing the device. There is a risk of dangerous and hot media escaping. Y O U R P A R T N E R F O R M E A S U R E M E N T & A U T O M A T I O N www.acs-controlsystem.com... -
Page 7: Field Enclosure
Connection current 4…20mA FSK / Pt100 – 3-wire Pt-A1 FSK-Interface Pt-B1 Pt-B2 240R FSK-Interface Pt100 240R YE/GN YE/GN Consider resistor 240Ω within wire +L for connection of the FSK-communication device. ACS-CONTROL-SYSTEM GmbH | Lauterbachstr. 57 | 84307 Eggenfelden | Germany info@acs-controlsystem.de | +49 (0) 8721/9668-0... -
Page 8: Electronic Output 09-V - Interface Rs485 Modbus-Rtu
Us = 6…35VDC Y O U R P A R T N E R F O R M E A S U R E M E N T & A U T O M A T I O N www.acs-controlsystem.com... -
Page 9: Operation
SV = Temperature 1022 Maximum SV = Temperature 1024 Minimum SV = Temperature Input Register – Values Read only Address Byte / Type Description Comment ACS-CONTROL-SYSTEM GmbH | Lauterbachstr. 57 | 84307 Eggenfelden | Germany info@acs-controlsystem.de | +49 (0) 8721/9668-0... -
Page 10: Service
Y O U R P A R T N E R F O R M E A S U R E M E N T & A U T O M A T I O N www.acs-controlsystem.com... -
Page 11: Technical Data
09-V: RS485 Modbus-RTU: 6…35VDC reverse polarity protected / ≤ 2Vpp / ≤ 10mA (no load) Input current Is Process conditions Process temperature Tp -20…+70°C (-4°F… 2158F) Pressure cycles ≥ 100 Mio. (1,2xPN) ACS-CONTROL-SYSTEM GmbH | Lauterbachstr. 57 | 84307 Eggenfelden | Germany info@acs-controlsystem.de | +49 (0) 8721/9668-0... -
Page 12: Field Enclosure
Terminals 3x/6x 0,2…4mm Y O U R P A R T N E R F O R M E A S U R E M E N T & A U T O M A T I O N www.acs-controlsystem.com... -
Page 13: Dimensions
Electrical connection 14-H Electrical connection 14-0 Confection stranded wires Confection Hydrolog HLF4 Without confection Dimensions in mm Field enclosure PE/PA H 57 M20x1,5 M20x1,5 Dimensions in mm ACS-CONTROL-SYSTEM GmbH | Lauterbachstr. 57 | 84307 Eggenfelden | Germany info@acs-controlsystem.de | +49 (0) 8721/9668-0... -
Page 14: Accessories
Dimensions in mm Y O U R P A R T N E R F O R M E A S U R E M E N T & A U T O M A T I O N www.acs-controlsystem.com... -
Page 15: Installation Material
In: 0/4…20mA/0..10V/RS485 Modbus-RTU/Digital-In Art.-No. 161000377 field installation isHRT USB Interface converter FSK - USB Art.-No. 611000595 Waveshare 15817 Interface converter RS485 - USB Art.-No. 611000588 ACS-CONTROL-SYSTEM GmbH | Lauterbachstr. 57 | 84307 Eggenfelden | Germany info@acs-controlsystem.de | +49 (0) 8721/9668-0... - Page 16 FEEL FREE TO CONTACT US ACS-CONTROL-SYSTEM GmbH Lauterbachstr. 57 84307 Eggenfelden - Germany info@acs-controlsystem.de www.acs-controlsystem.com +49 (0) 8721-9668-0 Y O U R PA R T N E R F O R M E A S U R E M E N T & A U T O M AT I O N...
