Loading The Cards - EasyBadge 2.0 User Manual

2.3. Loading the cards

This section shows how to load the plastic cards.
(1) Open the input hopper cover.
If you are not using standard
thickness cards (0.8 mm/760mircon)
Release two screws, insert a card to
use and fix screws after adjust the
card thickness device. 0.4mm to 0.8
mm cards are supported.
(Caution! If the adjustment is not correct, it
will can cause a print error. Use the type of
cards in the specification of this manual.
Always keep the cards clean and do not
touch the card surface.)
(2) To separate cards from each
other, push a stack of cards back
and forth to an angle about 45
degrees vertically.
(Static charge makes cards stuck with
significant adhesive force. These cards
must be physically separated from each
other before inserted into the feeder. If not
separated, feeding or printing problems
may occur.)
12 | P a g e
