Summary of Contents for Clarion Ungo MS2000
- Page 2 ongratulations on your purchase of this Ungo System. Please read this manual thoroughly to familiarize yourself with your system’s components and operation. Discuss any questions you might have with your installing dealer. Record the serial number of your Ungo system and keep all dealer records and receipts.
-
Page 3: Table Of Contents
Note: Certain features described in this manual may require additional parts and/or labor. Also, some features of the Ungo MS2000 system have selectable options that must be activated or programmed during the system’s installation. These items will be identified in the following sections. Your Authorized Ungo Dealer will be... -
Page 5: About Your Ungo Security System
Protect both you and the contents of your vehicle with features such as panic mode, dome light illumination*, and ignition controlled door locking*. * Optional Features Each Ungo MS2000 System comes with: • Main Unit - the “brain” of the system. • Two 3-Button Remote Transmitters •... -
Page 6: Remote Transmitters
Remote Transmitter Layout Button 1 Button 3 The Ungo MS2000 comes with 2 multi-function Remote Transmitters used to control nearly all of the system’s features. Each time a transmitter button is pressed, the LED will flash to indicate that a transmission is taking place. -
Page 7: Battery Replacement
Adding a New Transmitter into the System The Ungo MS2000 has the ability to recognize up to 4 individual Remote Transmitters. If the vehicle is used by multiple drivers, each can have their own Remote Transmitter. -
Page 8: Basic Features Remote Arming
Basic Features Remote Arming When Armed, the system monitors and protects 3 independent areas, or zones, including the doors, hood/trunk, and shock sensor. To Arm the System: 1. Turn off the ignition. 2. Press Button 1. • The siren/horn will chirp once.* •... -
Page 9: Remote Disarming
To Bypass the sensors: 1. After arming the system, press Button 1 again on the Remote Transmitter within 5 seconds. • The siren will chirp 5 times, indicating the sensors have been bypassed. 2. The sensors will remain bypassed until the next time the system is armed. Remote Disarming To Disarm the System: Press Button 2. -
Page 10: Passive Arming
To set the Arming Mode: 1. Turn the ignition on. 2. Within 4 seconds, press Button 3 to change the setting. one chirp Passive Arming with chirp two chirps Active Arming three chirps Passive without chirp 3. Turn the ignition off to save your selection. Passive Arming When the Arming Mode has been set for Passive Arming, the system arms itself automatically, each time the ignition is turned off and all of the doors, hood and trunk are closed. -
Page 11: Emergency Override
Emergency Override In case your Remote Transmitter becomes inoperable, or it is lost or stolen, you can still enter and drive your car by using the following procedure. Be sure that you have your ignition keys ready and that you know the location of the Override switch before you perform this procedure. To override the system: 1. -
Page 12: Other Features
Other Features Valet Mode Allows you to temporarily disable the security system when the car is being service or turned over to a parking attendant. To turn Valet Mode on or off: 1. Turn on the ignition. 2. Press and hold the override switch. 3. -
Page 13: Trunk Disarm
To operate the Auxiliary Function with the system Disarmed, press Button 3 for three seconds. • This function will stay active for as long as Button 3 is held. Trunk Disarm If the Auxiliary Function is being used to remotely open your car’s trunk, your installer can program the system to automatically disarm the alarm when the auxiliary function is pressed while the system is armed. -
Page 14: Technical Data
Technical Data Specifications Main Unit Voltage: 12v, negative ground Current Consumption: <15mA Temperature Range: -40 o F to +257 o F Auxiliary Output Capability: 500mA Internal Relays: (1) 30A, (1) 15A Transmitter Current Consumption: <.00mA, standby Battery Type: miniature 12v, type 23A Warranty Information Model No.: MS2000 Serial No.:... -
Page 15: Warranty
Warranty Information 1. Ungo Security Corporation of Gardena, California ("Ungo Security") warrants this Ungo system to be free from defects in materials and workmanship and to comply with Ungo Security’s applicable printed specifications. 2. Ungo Security systems carry a limited lifetime warranty on the Main unit (system brain) and transmitters. - Page 16 Ungo Security Corporation A Clarion Company 661 West Redondo Beach Blvd. Gardena, CA 90247 800-Go-Clarion www.clarion-usa.com © Ungo Security Corporation, Gardena, CA 97-MS2000-10 Rev. 1 (11/00)
