Summary of Contents for ALDI GARDENLINE ROCKING BISTRO SET 811944
- Page 1 Assembly Instructions ROCKING BISTRO SET ID: #05007...
- Page 2 Chairs Table...
-
Page 3: Contents
Contents Contents Chairs Table Left armrest, 2× Tabletop Right armrest, 2× Leg, 4× Sitting surface, 2× Leg support Backrest, 2× Connecting elements supplied Seat cushion, 2× Backrest cushion, 2× Spacer, 4× Connecting elements Bolt cap, 8× supplied Washer, 8× M6 × 25 bolt, 8× M6 ×... -
Page 4: Table Of Contents
Table of contents Table of contents Contents ........................3 Connecting elements supplied................. 3 Tools supplied ......................3 Required tools (not included) ................... 3 General information ....................5 Reading and storing the assembly instructions ............ 5 Proper use ........................5 Explanation of symbols ..................5 Safety ........................ -
Page 5: General Information
General information IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY! General information Reading and storing the assembly instructions These assembly instructions accompany this rocking bistro set (hereafter referred to as the “product”), and contain important information on setup and handling. Before using the product, read the assembly instructions carefully. This particularly applies to the safety instructions. -
Page 6: Safety
Safety Do not wash. Not suitable for bleaching. Not suitable for being dried in a tumble dryer. Not suitable for ironing. Not suitable for dry cleaning. Safety Signal symbol/word definitions The following symbols and signal words are used in these assembly instructions. This signal symbol/word designates a hazard WARNING! with moderate risk, which may result in death... - Page 7 Safety − The product can tip over when it is loaded too heavily or on one side. Make sure the load is evenly distributed. − Do not sit on the backrest or armrest of the rocking chairs. − Do not climb or stand on the rocking chairs or table. −...
-
Page 8: Product Description
Product description − Never attempt to clean the product by immersing it in water and do not use a steam cleaner to clean it. Otherwise the product could be damaged. − Check regularly the stability of all connections and retighten the bolts. -
Page 9: Basic Cleaning
Assembly Basic cleaning 1. Remove the packaging material and all plastic wrappings. 2. Clean all parts of the product before first use as described in the chapter “Cleaning and maintenance”. Assembly NOTICE! Risk of damage! Improper handling of the product may result in damage to the product. - Page 10 Assembly 1 Assembling the rocking chairs The rocking chairs produce a gentle rocking motion. Hold on to one of the armrests to keep your balance when sitting on or standing up from the rocking chairs. 1. Attach the left armrest and the right armrest to the sitting surface with one washer...
- Page 11 Assembly 3. Place the seat cushion and backrest cushion onto the rocking chair (see Fig. 3). 4. Secure the cushions on the rocking chair with the hook and loop fasteners at the back of the cushions. 5. Repeat the steps above to assemble another rocking chair. The rocking chairs are ready for use.
- Page 12 Assembly 2. Insert the legs into the brackets on the underside of the tabletop secure each leg to the tabletop with one M4 × 12 screw (see Fig. 5). 3. Attach the leg support to the legs with two M6 × 40 mm bolts two washers and two nuts at each connection.
-
Page 13: Cleaning And Maintenance
Cleaning and maintenance 4. Turn the table over and place it on a flat and stable surface with all legs touching the ground surface (see Fig. 7). The table is ready for use. Cleaning and maintenance Cleaning NOTICE! Risk of damage! Improper handling of the product may result in damage. -
Page 14: Maintenance
Technical data Maintenance − Always protect the cushions from rain and moisture. They are not suitable to be used in a wet environment. − Regularly check that all bolt and screw connections are tight and re-tighten if necessary. Loose bolt and screw connections may impair safety. There is a risk of injury. -
Page 15: Disposal
Disposal Disposal Disposing of the packaging Sort the packaging before you dispose of it. Dispose of paperboard and cardboard with the recycled paper service and wrappings with the appropriate collection service. Disposing of the product − Dispose of the product in accordance with the applicable laws and regulations for your country. - Page 16 PRODUCED IN CHINA FOR: ALDI STORES LTD. PO BOX 26, ATHERSTONE WARWICKSHIRE, CV9 2SH ALDI STORES (IRELAND) LTD. PO BOX 726, NAAS, CO. KILDARE Visit us at www.aldi.com...
