NAPOLI HANGING UMBRELLA WITH BIG BASE
!
READ & SAVE BELOW INSTRUCTIONS
There are two installation methods for this product. If you are using a thick umbrella stand as shown in
the figure, please use this manual.
Before beginning assembly of product, make sure all parts are present. Compare parts with package
contents list and hardware contents list. If any part is missing or damaged, do not attempt to assemble
the product.
This item is heavy. Use care when handling. May require two adults for safe assembly.
Assemble the items on a stable, non-abrasive surface such as carpeting to avoid damage.
CARE AND MAINTENANCE
Use mild soap and warm water. Do not use abrasive materials, cleaners or bleach products. Rinse with
clean water and dry thoroughly.
Water allowed to accumulate inside the frames could freeze and damage the frame tubing.
Such damage is not covered under the warranty.
During inclement weather conditions and winter period, please close the umbrella and store it in a dry
area. A matching umbrella cover is strongly recommended to extend the usage life-span.
1-16
