Permaban AlphaJoint Installation Guide
Using AlphaFix Method
Installation Guide Issue V2.0
23/11/21

05 Adjust to Height

Check height is correct, adjust the 30mm nut on top of the AlphaFix to achieve height required,
ensuring the joint is level using a spirit level/optical level.
Note;
Joints must be fixed at 90°.
Level
Top strip
Height Adjusting nut
Note;
Check the joint is level in the 3 positions above.
Note;
Measure the vertical and
horizontal level using the
top strip.
All content found within this installation guide is approximate. RCR Flooring Products Ltd reserves the right to
amend this installation guide at any time. For further details, please contact RCR Flooring Products Ltd.
