- Page 1 PON ONT GE-PON ONT 01LL Installation Guide ubiQuoss Inc. 24F Millennium B/D, 467-12 Dogok-Dong Gangnam-Gu, Seoul 135-700 Korea TEL: +82-70-8666-5000 FAX: +82-2-2190-3201 E-mail: oversea.team@ubiQuoss.com...
-
Page 2: Key Features
PON ONT Overview The C501LL is an ONT (Optical Network Terminal) based on EPON te chnology for home and small office. It s upports 1 Gigabit Ethernet (UTP, RJ45) ports to the subscriber. It is connected to GE-PON OLT and RN (Remote Node) via a fiber optic cable to provide TPS (Triple Play Service). -
Page 3: Contents Of The Package
PON ONT Contents of the Package User Guide C501LL RJ45 Cable Power Adaptor Precautions Warning Before y u install the C501LL, read this section. This section contains important safety information u should know before w orking with the system. Power Consider ations ... -
Page 4: Disposing Of The System
PON ONT Connecting Cables When you connect cables, note the following guidelines. Do not work on the system or connect or disconnect cables during periods of lightning activity. Working wit h Lasers If your system inc ludes a fiber-optic port, note the following guidelines. ... -
Page 5: Installation
PON ONT Installation Wa ning Invisible laser radiation may be emitted from disconnected fibers or connectors. Do not stare into beams or view directly with optical instruments. 1. Open the bottom cover case. Grip the ONT upside down. Then pull the bottom cover case up with your ... - Page 6 PON ONT . Connect the rated power adaptor (5V 2A) provided together with C501LL main body. PON Splitter 5. Turn on the power switch. 6. Make sure that th e PWR LED is ON. 7. Make sure that LAN LED is ON. 8.
-
Page 7: Front Panel
PON ONT System Architecture Front Panel Name Color Status Function Actions to take Power ON Check Power switch at the GREE back panel-> Power OFF Power adapter & power outlet Link Up (Normal) Normal Operation GREEN Link Down. Opt ic signal ON Call Service Provider Line (Every... -
Page 8: Rear Panel
PON ONT Rear Panel Indication Description Line 1.25G PON Port Gigabit Ethernet Port 5.0V 2.0 A Power Terminal ON/OFF Power Switch... -
Page 9: Troubleshooting
PON ONT Troubleshooting: ymptom: Can not access to the Internet; Step 1 Make sure that the ONT is turned on. Once you turn on the power, the PWR LED on the front panel of C501LL should be turned on. If the PWR LED is turned OFF, please check if the power cable is connected to the po wer inlet of ONT properly or switch of power strip if any is turned ON. -
Page 10: Specification
PON ONT Specification Item Description Standard IEEE 802.3ah Type Desktop System Architecture Size (mm) 180(W) x 135(D) x 40( Input: 110~220 V ±15%, 60 ± 3Hz Power Output: +5V, 2A (power ad aptor used) Consumption: Max 4.0W PON interface 1.25G 1000Base-PX, 1 Core SMF Available Interface User interface one port 10/100/1000base-Tx (IEEE 802.3u) - Page 11 PON ONT - Transmission distance: 10 Km or 20Km(Optional) Physical Optical charac teristics - Transmission q uality: BER 10-10 or lower Characteristics - Transmission level : -1~4dBm Dielectric resistance 100Mohm or higher (based on DC 500V) - IEEE Std 802.3™-2002 Carrier sense multiple access with collision detection (CSMA/CD) access method and ph ysical layer specifications...
