NANLUX TK-200 Manual

Led daylight soft panel light
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
USER MANUAL
TK-200/TK-450
LED DAYLIGHT SOFT PANEL LIGHT
WWW.NANLUX.COM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TK-200 and is the answer not in the manual?

Questions and answers

Related Manuals for NANLUX TK-200

Summary of Contents for NANLUX TK-200

  • Page 1 USER MANUAL TK-200/TK-450 LED DAYLIGHT SOFT PANEL LIGHT WWW.NANLUX.COM...

  • Page 2: Table Of Contents

    Contents Product Diagram ............4. MENU Key ........................Technical Data ①ADDRESS/DMX ............②WIRELESS PROTOCOL ..........Product Details ............③LUMENRADIO SETTINGS ......... Detailed Description ..........④ROTATE SCREEN ........... ⑤SCREEN BRIGHTNESS ........... Power Connection ............ ⑥BUTTON BACKLIGHT ..........Remote Control ⑦LANGUAGE ............

  • Page 3: Product Diagram

    TK-200/TK-450 LED Daylight Soft Panel Light Product Diagram TK-450 TK-200 Technical Data Model No.: TK-200 Model No.: TK-450 Rated power: 240W Rated power: 455W Input voltage/current: DC24V/10.4A Max Input voltage/current: DC48V/10A Max AC100-240V 50/60HZ AC100-240V 50/60HZ CCT: 5600K CCT: 5600K...

  • Page 4: Product Details

    Product Details 1. Fixture 1. Fixture body handle body handle 2. Kipp handle 2. Kipp handle 8. Mounting plate 3. Yoke 9. User interface 4. Power indicator 10. Safety cable ring 5. USB port 6. DMX IN 11. Power switch 12.

  • Page 5: Detailed Description

    Detailed Description 1. Fixture body handle: For lift the fixture and adjust the direction of the fixture. 2. Kipp handle: Tighten or release the tilt movement of the fixture on the yoke. 3. Yoke: Mount the fixture on a stand; pan and tilt. 4.

  • Page 6: Power Connection

    1. When connecting the power supply, please make sure the power, voltage and frequency is consistent with the provided power supply. ① ▲Note: Make sure to use the provided power supply and power cable. ② The connection between plug on power supply and the power cable on the fixture should be connected as following. ·TK-200 DC IN ·TK-450...

  • Page 7: Remote Control

    Remote Control ·TK-200/TK-450 supports remote control via DMX, 2.4G, RDM, LUMENRADIO, and has built-in bluetooth. ▲ The ADDRESS needs to be set before operating the remote control via DMX, 2.4G, RDM and LUMENRADIO. 1. ADDRESS/DMX, including ADDRESS, DMX MODE and DMX DIMMING CURVE setting.
  • Page 8 Rotate ''Upper knob'' to select the desired ADDRESS number and press ''Upper knob'' to set. Note: TK-200/TK-450 has 9 channels, for multiple lights remote control via DMX, 2.4G, RDM, LUMENRADIO, the address of the first light is set to 001, the second...
  • Page 9 ② DMX MODE MENU MENU CH: 512 CH: 512 ADDRESS DAYLIGHT 8bit DMX MODE ULTIMATE DMX 8bit DMX DIMMING CURVE PRESS “MENU” TO RETURN PRESS “MENU” TO RETURN Rotate ''Upper knob'' to DMX MODE and press ''Upper knob'' to enter the correspoding secondary menu. MENU MENU CH: 512...

  • Page 10: Dmx Remote Control

    ③ DMX DIMMING CURVE MENU MENU CH: 512 CH: 512 ADDRESS LINEAR DMX MODE EXPONENT DMX DIMMING CURVE LOGARITHM S CURVE PRESS “MENU” TO RETURN PRESS “MENU” TO RETURN Rotate ''Upper knob'' to DMX DIMMING CURVE and press ''Upper knob'' to enter the correspoding secondary menu. MENU MENU CH: 512...
  • Page 11 Set the address of the fixture. ④ Refer to the attached DMX reference guide and control the light via DMX512 console. (For specific operation methods, please refer to the DMX512 console operation manual.) Note: DMX Reference Guide《 TK-200/TK-450 DMX Reference Guide (NANLUX))》please download from www.nanlux.com...

  • Page 12: Remote Control

    3. 2.4G Remote Control Set the address of the 2.4G remote controller to be consistent with the light fixture, then the light fixture can be remotely controlled by 2.4G remote controller or by APP via the 2.4G transfer device. ① Note: 2.4G remote controller and 2.4G transfer device are sold separately.

  • Page 13: Rdm Remote Control

    ② Control the fixture via a console with RDM function. (For specific operation methods, please refer to the RDM console operation manual.) Note: The UID format of the fixture is as follows: 0008 XXXX XXXX Serial number 0303：TK-200 0304：TK-450 Manufacture: Nanguang...

  • Page 14: Lumenradio Remote Control

    5. LUMENRADIO Remote Control ·TK series has built-in TIMO RX module, enabling it to receive CRMX wireless DMX signal. The opreation method is as following: ① Set the fixture that need to receive CRMX wireless DMX signals to UNLINK. Press the ''MENU'' Key to access options. MENU CH: 512 ADDRESS/DMX...
  • Page 15 MENU MENU CH: 512 CH: 512 UNLINK DO YOU WANT TO UNLINK? PRESS “MENU” TO RETURN PRESS “MENU” TO RETURN Rotate "Upper knob" to enter the next menu. MENU MENU CH: 512 CH: 512 DO YOU WANT TO UNLINK? PRESS “MENU” TO RETURN PRESS “MENU”...

  • Page 16: Operating Instructions

    1. Make sure the power switch is in the "off" position, then connect the fixture to the power supply with power cable. Then turn on the power switch, if the indicator is normally on, the screen will first display “NANLUX”, that means the power is active.

  • Page 17: Effect Key

    3. EFFECT Key: Press the Effect key to enter the operation interface of EFFECT mode, rotate "Lower knob"to select the desired special effect. TK-200/TK-450 has built-in special effects: INT LOOP, FLASH, PULSE, STORM AUTO, STORM MANUAL, TV, PAPARAZZl, CANDLE/FIRE, BAD BULB, FIREWORK, EXPLOSION AUTO, EXPLOSION MANUAL, WELDING.
  • Page 18 ① INT LOOP For INT LOOP settings, rotate "Upper knob" to select DIM and SPEED (Range:2S-30S), then rotate "Lower knob" to set the corresponding parameters. EFFECT MODE EFFECT MODE CH: 512 CH: 512 EFFECT: INT LOOP EFFECT: INT LOOP DIM: 0%-100% DIM: 0%-100% SPEED: 8s SPEED:...
  • Page 19 ② FLASH For FLASH settings, rotate "Upper knob" to select DIM, INTERVALS (Range:0.1s-10.0s) and FLASH RATIO (Range: 0% -100%), then rotate "Lower knob" to set the corresponding parameters. EFFECT MODE EFFECT MODE CH: 512 CH: 512 EFFECT: FLASH EFFECT: FLASH DIM: 100% DIM: 100% INTERVALS: 1.0s...
  • Page 20 ③ PULSE For PULSE settings, rotate "Upper knob" to select DIM and PULSES/MIN (Range:1-240), then rotate "Lower knob" to set the corresponding parameters. EFFECT MODE EFFECT MODE CH: 512 CH: 512 EFFECT: PULSE EFFECT: PULSE DIM: 100% DIM: 100% PULSES/MIN: 40 PULSES/MIN: Rotate ''Upper knob'' to select DIM and PULSES/MIN.
  • Page 21 ④ STROM AUTO For STROM AUTO settings, rotate "Upper knob" to select DIM, INTVL RANGE (Range: 1s-60s), then rotate "Lower knob" to set the corresponding parameters. EFFECT MODE EFFECT MODE CH: 512 CH: 512 EFFECT: STORM AUTO EFFECT: STORM AUTO DIM: 100% DIM: 100% INTVL RANGE: 2s - 6s...
  • Page 22 ⑤ STROM MANUAL For STROM MANUAL settings, rotate "Upper knob" to select DIM, then rotate "Lower knob" to set the corresponding parameters and press "Upper knob" to trigger storm. EFFECT MODE EFFECT MODE CH: 512 CH: 512 EFFECT: STORM MANUAL EFFECT: STORM MANUAL DIM: 100% DIM:...
  • Page 23 ⑥ For TV settings, rotate "Upper knob" to select DIM and SPEED (Range:1-100). Then rotate "Lower knob" to set the corresponding parameters. EFFECT MODE EFFECT MODE CH: 512 CH: 512 EFFECT: EFFECT: TV DIM: 0% - 100% DIM: 0% - 100% SPEED: 50 SPEED: Rotate "Upper knob"...
  • Page 24 ⑦ PAPARAZZI For PAPARAZZI settings, rotate the "Upper knob" to select DIM and SPEED (Range:1-100), then rotate "Lower knob" to set up the corresponding parameters. EFFECT MODE EFFECT MODE CH: 512 CH: 512 EFFECT: PAPARAZZI EFFECT: PAPARAZZI DIM: 100% DIM: 100% SPEED: 50 SPEED: Rotate "Upper knob"...
  • Page 25 ⑧ PCANDLE/FIRE For CANDLE/FIRE settings, rotate "Upper knob" to select DIM and SPEED (Range: 1-100), then rotate "Lower knob" to set the corresponding parameters. EFFECT MODE EFFECT MODE CH: 512 CH: 512 EFFECT: CANDLE/FIRE EFFECT: CANDLE/FIRE DIM: 0% - 100% DIM: 0% - 100% SPEED: 50 SPEED:...
  • Page 26 ⑨ BAD BULB For BAD BULB settings, rotate "Upper knob" to select DIM, INTENSITY (Range:1-100) and SPEED (Range:1-100), then rotate "Lower knob" to set the corresponding parameters. EFFECT MODE EFFECT MODE CH: 512 CH: 512 EFFECT: BAD BULB EFFECT: BAD BULB DIM: 100% DIM: 100% INTENSITY: 50...
  • Page 27 ⑩ FIREWORK For FIREWORK settings, rotate "Upper knob" to select DIM and SPEED (Range: 1-100) and DECAY (Range:1-100), then rotate "Lower knob" to set the corresponding parameters. EFFECT MODE EFFECT MODE CH: 512 CH: 512 EFFECT: FIREWORK EFFECT: FIREWORK DIM: 100% DIM: 100% SPEED: 50 SPEED: 50...
  • Page 28 ⑪ EXPLOSION AUTO For EXPLOSION AUTO settings, rotate "Upper knob" to select DIM, SPEED (Range:1-100) and DECAY (Range:1-100), then rotate "Lower knob" to set the corresponding parameters. EFFECT MODE EFFECT MODE CH: 512 CH: 512 EFFECT: EXPLOSION AUTO EFFECT: EXPLOSION AUTO DIM: 100% DIM: 100% SPEED: 50...
  • Page 29 ⑫ EXPLOSION MANUAL For EXPLOSION MANUAL settings, rotate "Upper knob" to select DIM and DECAY (Range:1-100), then rotate "Lower knob" to set the corresponding parameters. EFFECT MODE EFFECT MODE CH: 512 CH: 512 EFFECT: EFFECT: EXPLOSION MANUAL EXPLOSION MANUAL DIM: 100% DIM: 100% DECAY: 50 DECAY:...
  • Page 30 SPEED: 50 SPEED: 50 PAUSE: PAUSE: Rotate ''Lower knob'' to set the corresponding parameters. Note: When the PAUSE is ON, WELDING paused. ·Lighting effects and additional functionality maybe added with future firmware releases, for details of these please see www.nanlux.com.

  • Page 31: Menu Key

    4. MENU Key: Press MENU key to access options. MENU CH: 512 ADDRESS/DMX WIRELESS PROTCOL LUMENRADIO SETTINGS ROTATE SCREEN SCREEN BRIGHHTNESS BUTTON BACKLIGHT ·Rotate "Upper knob" to select setting item, press "Upper knob" to enter corresponding secondary menu, rotate "Upper knob" again to select corresponding option, press "Upper knob"...

  • Page 32: ④Rotate Screen

    ④ ROTATE SCREEN MENU MENU CH: 512 CH: 512 ADDRESS/DMX WIRELESS PROTCOL Do you want to rotate screen LUMENRADIO SETTINGS ROTATE SCREEN SCREEN BRIGHHTNESS BUTTON BACKLIGHT PRESS “MENU” TO RETURN Rotate ''Upper knob'' to ROTATE SCREEN and press "Upper knob" to enter the correspoding secondary menu. MENU CH: 512 Do you want to rotate screen...

  • Page 33: ⑤Screen Brightness

    ⑤ SCREEN BRIGHTNESS MENU MENU CH: 512 CH: 512 ADDRESS/DMX WIRELESS PROTCOL SCREEN BRIGHTNESS LUMENRADIO SETTINGS ROTATE SCREEN SCREEN BRIGHHTNESS BUTTON BACKLIGHT PRESS “MENU” TO RETURN Rotate ''Upper knob'' to SCREEN BRIGHTNESS and press ''Upper knob'' to enter the correspoding secondary menu. MENU MENU CH: 512...
  • Page 34 ⑥ SCREEN BRIGHTNESS MENU MENU CH: 512 CH: 512 ADDRESS/DMX WIRELESS PROTCOL LUMENRADIO SETTINGS ROTATE SCREEN SCREEN BRIGHHTNESS BUTTON BACKLIGHT PRESS “MENU” TO RETURN Rotate ''Upper knob'' to BUTTON BACKLIGHT and press ''Upper knob'' to enter the correspoding secondary menu. MENU MENU CH: 512...

  • Page 35: ⑦Language

    ⑦ LANGUAGE MENU MENU CH: 512 CH: 512 WIRELESS PROTCOL ENGLISH LUMENRADIO SETTINGS 中文 ROTATE SCREEN SCREEN BRIGHHTNESS BUTTON BACKLIGHT LANGUAGE PRESS “MENU” TO RETURN Rotate ''Upper knob'' to LANGUAGE and press ''Upper knob'' to enter the correspoding secondary menu. MENU CH: 512 菜单...

  • Page 36: ⑧Version

    USB drive that has BUTTON BACKLIGHT new firmware, and restart the light LANGUAGE www.nanlux.com VERSION PRESS “MENU” TO RETURN Rotate "Upper knob" to VERSION , and press "Upper knob" to check the current version. 5. Long press the LOCK Key to lock functions, now operation keys or adjustment knobs cannot change the current function, long press the Lock key again to release the Lock status.

  • Page 37: Safety Precautions

    Safety Precautions 1. Please open the package to check for damage caused in transit, if damaged please do not use and contact place of purchase or manufacturer as soon as possible. 2. Do not use a power cable with damaged insulation. Do not unplug hard or drag the power cable directly. 3.

  • Page 38: Product Includes

    What's in the box? Please kindly check. TK-200 x 1 DMX Reference Guid x 1 User Manual x 1 Power Supply Power Cable USER MANUAL USER MANUAL TK-200/TK-450 TK-200/TK-450 DMX REFERENCE GUIDE LED DAYLIGHT SOFT PANEL LIGHT WWW.NANLUX.COM WWW.NANLUX.COM TK-450 x 1...
  • Page 39 Version: V4 2021-04-29 +86-754-85751187 +86-754-85300887 info@nanlux.com Zhanglin,324,Dongli Chenghai Shantou Guangdong China Guangdong NanGuang Photo&Video Systems Co., Ltd...
