- Page 1 Fivestars-Pegasus Instructions 1. General Description SBC2.0a model is just a semi-finished product, and it can be applied to industrial and consumer.
-
Page 2: Product Specification
2. Product Specification 2.1 Function Block diagram 2.2 Function Specification Item Description Model SBC2.0a Major Chipset RK3399 Emmc Storage 16GB Ethernet Gigabit LAN WiFi/BT AP6398S 2T2R 802.11 a/b/g/n/ac + Bluetooth5.0 DC input DC Jack, 2.1x5.5mm Standard Spearker 2P/2.0MM JST Jack... -
Page 3: Interface Instructions
Make sure both ends of the network cable are plugged in, and that the corresponding network port is patched at the switch. 2) Display Connect the FPC port on SBC2.0a with your LCD Display device. The LCD display device must be MIPI interface. 3) AC Power Once the Box is plugged in, it will boot up. - Page 5 Placement Pin No. Function Description ED35 AZ5725-01F ESD0402 ED35 AZ5725-01F ESD0402 ED36 AZ5725-01F ESD0402 ED36 AZ5725-01F ESD0402 Ground CON31 Ground UART_TX UART_TX CON23 UART_RX UART_RX Ground VCC_TP VCC_TP VCC_TP VCC_TP I2C2_SDA_3V3 I2C2_SDA_3V3 I2C2_SDA_3V3 I2C2_SDA_3V3 Ground Ground TP_INT TP_INT TP_RST TP_RST MCU_TX MCU_TX VCC1V8_S3...
- Page 6 Ground DC12V Power DC12V Power DC12V Power DC12V Power DC12V Power Ground Ground Power Power in TYPE-C USB Port RJ50 Connect LAN...
-
Page 7: Fcc Statement
FCC Statement This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user ’... - Page 8 important announcement Imp ortant Note: Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator and your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
- Page 9 Important Note: In the event that these conditions cannot be met (for example certain laptop configurations or co-location with another transmitter), then the FCC authorization is no longer considered valid and the FCC ID cannot be used on the final product. In these circumstances, the OEM integrator will be responsible for re-evaluating the end product (including the transmitter) and obtaining a separate FCC authorization.
- Page 10 Integration instructions for host product manufacturers according to KDB 996369 D03 OEM Manual v01 2.2 List of applicable FCC rules CFR 47 FCC PART 15 SUBPART C has been investigated. It is applicable to the modular transmitter 2.3 Specific operational use conditions This module is stand-alone modular.
- Page 11 Antenna No. Model No. of Type of antenna: Gain of the antenna Frequency range: antenna: (Max.) 2.65dBi 2400-2500MHz BT/2.4GWIFI/5GWIFI PCB antenna 1.83dBi 5100-5250MHz Antenna 0 3.00dBi 5700-5850MHz 2.65dBi 2400-2500MHz 2.4GWIFI/5GWIFI PCB antenna 1.83dBi 5100-5250MHz Antenna 1 3.00dBi 5700-5850MHz 2.8 Label and compliance information The final end product must be labeled in a visible area with the following"...
- Page 12 ISED Statement - English: This device complies with Industry Canada license ‐ exempt RSS standard(s). Operation is subject to the following two conditions: (1) This device may not cause interfe rence, and (2) This device must accept any interference, including interference that may cause undesired operation of the device.
- Page 13 Dans le cas où ces conditions ne peuvent pas être remplies (par exemple, certaines configurations d'ordinateur portable ou la co-implantation avec un autre émetteur), alors l'autorisation d'ISDE n'est plus considérée comme valide et le numéro de certification d'ISDE ne peut pas être utilisé sur le produit final. Dans ces circonstances, l'intégrateur du FEO sera responsable de la réévaluation du produit final (y compris l'émetteur) et de l'obtention d'une autorisation d'ISDE distincte.
