- Page 1 COTX-X3 Gateway Intelligent IoT Gateway Quick Start Guide...
-
Page 2: Package Contents
•Power Adapter*1pcs •Power Cable*1pcs •Ethernet Cable*1pcs •LoRa® Antenna*1pcs Size The MCO (Maximum outline dimension) of COTX-X3 is 75 x 95 x 29 mm, as shown below: LoRa® Reserved Power Input Camera Audio Output Display Screen Antenna port For RS485 Extension... - Page 3 LED and Screen User Guide Indicator Description Preparing COTX-X3 Gateway Step 1: Install the LoRa antenna on the LoRa Antenna port. LoRa® Antenna port Type Status Description No Power LED Light Blink System Start System Operate Short press BT BUTTON, turn on/off the screen...
- Page 4 A�er the power connec�on, the LED would light up and turn green when it's ready for further configura�on. IP Ethernet Port address would show on the screen for Ethernet cable connect to WAN/Internet scenario. Click the BT bu�on and the screen will display the Ethernet IP and device status.
- Page 5 Open Helium applica�on and login. Step 1: Turn on COTX Gateway’s BT, so the Step 2: Helium APP can detect the gateway to further Step 3: Tap “Add a Hotspot” and pick “COTX configura�on. Press the BT bu�on for 5 Gateways”...
- Page 6 Back Back 1 Hotspot found. Select your Hotspot to continue. Bluetooth CotxNetworks X3 Miner 0B:99 Press and hold the BT button for 5 seconds to turn on Bluetooth. The Hotspot is ready to pair when the screen displays the Bluetooth icon.
- Page 7 Wi-Fi Select the Wi-Fi network you'd like your Hotspot to connect to. Enter Password Scan Networks Enter your Wi-Fi’s credentials to connect your Hotspot to this Network. Configured Network cotx-office cotx-office Password Available Networks cotx-vip-2.4 Show Password cotx-office CICCWN SQNR...
- Page 8 Follow the App’s instruc�ons to posi�oning the gateway’s loca�on. Step 7: Back Set Hotspot Location We need to set a location for your Hotspot. We can use your phone to do this. First,we’ll ask for permission to access your phone’s location. Hotspot Location 阜通东大街，北京市...
- Page 9 Step 8: Tap “Register Hotspots“ to register the gateway in the Helium Network. It will take you approxi- mately 15 minutes to join the Helium network. Then the whole setup process is done. Back Location Fee Your Location Fee ($10) has been prepaid.
- Page 10 Quick Specifications Quick Specification Product Weight 203g Fixing Way Desktop Opera�ng 0℃~50℃ Power Supply 5V DC input power supply Temperature Maximum Power CN470,EU433,US915, AS923, AS920, <10W Frequency Consump�on AU915,EU868, IN865, KR920 2GB LPDDR4-3200 SDRAM Quad-core Cortex-A72 @1.5GHz (4G/8G Op�onal) Ubuntu20.04 Main-board Raspberry Pi 4B 1* 10/100/1000M Ethernet interface...
- Page 11 Tel: +86-755-21014279 Website: www.cotxnetworks.com E-mail: support@cotxnetworks.com...
