- Page 1 COTX-X5 Outdoor Gateway COTX-X5 Outdoor Gateway Intelligent IOT Gateway Quick Start Guide Beijing COTX Networks Technologies Co., Ltd. www.cotxnetworks.com...
-
Page 2: Package Contents
COTX-X5 Outdoor Gateway Package Contents Your COTX-X5 Outdoor Gateway comes with the following items: 1 COTX-X5 outdoor gateway 3 installation kit 4 fixing screws (including accessories) 2 long connecting rod screws (including nuts) 1 ground screw ... - Page 3 Before outdoor installation, make sure you tighten all connectors and the case itself very well to avoid any unintended water ingress. Structure size The outer dimension of COTX-X5 is 227 x 82 x 192 mm, as shown below: Beijing COTX Networks Technologies Co., Ltd. www.cotxnetworks.com...
-
Page 4: Interface Description
Max Emitting Power 923.3~927.5MHz 27dBm US915, AS923, AS920, AU915,EU868, IN865, Frequency KR920 500 kHz LoRa reception with 8 x 8 channels LoRa® Channel packet detectors, 8 x SF5-SF12 LoRa® demodulators,8 x SF5-SF10 LoRa® demodulators Beijing COTX Networks Technologies Co., Ltd. www.cotxnetworks.com... - Page 5 1*Micro SD card LoRa Antenna N-Male*1,860~930MHz, Gain:3.5dBi N-Male*1 860~960MHz,1710~2700MHz, 4G Antenna Gain:3dBi WiFi/BT Antenna N-Male*1,2.4GHz/5GHz, Gain:6dBi LED Indicator System Indicator Green*1 Internet Indicator Green*1 WiFi Indicator Green*1 LTE Indicator Green*1 BLE/LoRa Indicator Green*1 Beijing COTX Networks Technologies Co., Ltd. www.cotxnetworks.com...
- Page 6 Place the base bracket on the back of the device with four M6*4 screws as shown below: Step2 Attach the 3-Axis brackets on the back of the device with two number 7 screws as shown below: Beijing COTX Networks Technologies Co., Ltd. www.cotxnetworks.com...
- Page 7 COTX-X5 Outdoor Gateway Step3 Insert the steel band clamps through the four holes on the mount kit, wrap the band clamps around the mounting pole, lock and tighten the clamps using a screwdriver. Beijing COTX Networks Technologies Co., Ltd. www.cotxnetworks.com...
-
Page 8: Wall Mounting
Use Ø5mm drill head, drill 4 holes on the wall according to the position of wall mounting bracket, plug the screw anchors to the wall, and fix the device to the wall as shown below; Beijing COTX Networks Technologies Co., Ltd. www.cotxnetworks.com... - Page 9 The default setting is Power over Ethernet (PoE). Connect the Ethernet port of the gateway to a switch with PoE function (PoE - IEEE 802.3af or IEEE 802.3at). If unavailable, use a PoE injector and power Power on by PoE Switch Beijing COTX Networks Technologies Co., Ltd. www.cotxnetworks.com...
- Page 10 Google Play directly by searching “Helium”. Please create a Helium wallet account first and continue to the next steps below: Step 1: Turn on COTX Gateway, so the Helium APP can detect the gateway to further configuration. Step 2: Open the Helium application and login.
- Page 11 COTX-X5 Outdoor Gateway Step 4: Follow the steps on the App and get to the “Bluetooth” page. Gateway Bluetooth is automatically turned on after the COTX outdoor device is powered up. Simply click “Scan for my Hotspot” to pair up.
- Page 12 COTX-X5 Outdoor Gateway Step 6: On the app it will show the available Wi-Fi networks within the range of your Gateway. If you are using Ethernet, tap Use Ethernet Instead and skip to Step 7. Beijing COTX Networks Technologies Co., Ltd. www.cotxnetworks.com...
- Page 13 If using Wi-Fi, tap on the name of your Wi-Fi network on the app which will bring you to the following screen. Type in your Wi-Fi’s network password then tap Connect and it will connect to your Wi-Fi network. Beijing COTX Networks Technologies Co., Ltd. www.cotxnetworks.com...
- Page 14 Step 8: Register the gateway to the Helium Network to provide IOT services for related devices. the setup is now complete. It’ll submit the details of the COTX Gateway to the Helium network. In approximately 15 minutes, will confirm it’s added to the Helium network.
- Page 15 COTX-X5 Outdoor Gateway Beijing COTX Networks Technologies Co., Ltd. www.cotxnetworks.com...
