OP GT – Manual v0.2 – January 13th, 2021...
Page 2
• Product includes small parts, please take special care if you have children in your household not to allow them to have access to the small parts. • If you encounter any issues or have any questions regarding our products, contact us at support@overpower.gg. We are happy to help you!
Page 3
• After opening the boxes, check the parts received and compare them to the part list to make sure you have received all the parts for the product • In case there’s a part missing, contact us at support@overpower.gg...
Page 7
Package: OP Frontal Assembly Mount the reinforcement board (AJ) to 3060 profile (F) with M8 slides (E) and screws (AC). If you are also installing the OP Electric Pedal Adjuster, add two additional slides (E) to lower slot.
Page 8
Attach 3060 profiles (F) to front board (M) with screws (AD)
Page 9
Insert slides (D) to front 3060 profiles. Make sure to insert them in the slots shown above.
Page 10
Attach the front board (N) with screws (AD) to 3060 profiles.
Page 11
Package: OP Frontal Assembly Connect the reinforcement board (AJ) to front boards with screws (W), washers (BK) and slides (D)
Page 12
Package: OP Frontal Assembly Attach levers (X) to side boards with washers (Y) and sliders (E)
Page 13
Package: OP Frontal Assembly Attach profiles (A) to slides and put levers to the lowest position...
Page 14
Package: OP Frontal Assembly Insert slides (E) to profiles...
Page 15
Package: OP Wheel & Pedal Rack Pro Attach wheel plate (AM) to profiles with screws (AB), washers (Y, note that washers are not shown in the picture) and slides inserted in the previous phase...
Page 16
Package: OP Wheel & Pedal Rack Pro Insert endcaps (C)
Page 17
Package: OP Wheel & Pedal Rack Pro Connect linear guides (O) to 3060 profiles using M6 Slides (D) and screws (T). Before you tighten the guides, align the distance between the guide and side plate with jig (HC) included.
Page 18
Package: OP Wheel & Pedal Rack Pro Connect linear guides (O) to 3060 profiles using M6 Slides (D) and screws (T). Before you tighten the guides, align the distance between the guide and side plate with jig (HC) included.
Page 19
Slide in the blocks (H) to the linear guides...
Page 20
Attach the pedal plate adapters (AF) to pedal side plates with screws (AA) and slides (E)
Page 21
Attach the pedal side plates to blocks (H) with M6x20 (U) screws...
Page 22
In case you are installing OP Electric Pedal Adjuster, after completing this phase follow it’s manual to insert the holder. Attach the cross support (BX) to pedal side plates with screws (BY) and slides (E)
Page 23
Attach the pedal plate (AE) with screws (AB) and slides (E)
Page 24
Package: OP Wheel & Pedal Rack Pro Tighten the blocks to guides with M6 Levers (R)
Page 25
Attach catches (BH) with screws (BI) Package: OP GT Base...
Page 26
In case you’re also installing OP Single or Triple Monitor Mount, insert two 3030 M8 Slides per outer profile slot (G) (total of 4 slides) Attach 3090 profile (G) to front side boards with screws (AD) and washers (Y). Package: OP Frontal Assembly...
Page 27
Package: OP GT Base Attach backboard to 3060 profiles...
Page 28
Package: OP GT Base Prepare 3030 corner brackets...
Page 29
Package: OP GT Base Attach corner brackets to 3030 profiles using the slides. Observe the orientation of the brackets from above.
Page 30
Package: OP GT Base Attach the 3030 profiles to 3060 profiles with corner brackets.
Page 31
Package: OP GT Base Insert slides to 3060 profile top slot.
Page 32
Package: OP GT Base Mount the HPL seat base with screws and slides inserted in the previous phase...
Page 33
Package: OP GT Base Attach screws and slides with washers to side board slots...
Page 34
Package: OP GT Base Attach latches to side boards...
Page 35
Package: OP GT Base Attach seat base to side boards...
Page 36
Package: OP GT Base Loosen the side board screws and attach seat base to frontal assembly...
Page 37
Package: OP GT Base Tighten the side board screws...
Page 38
Package: OP GT Base Unmount the seat base, turn it sideways, mount the seat of your choosage and start racing! Be careful with handling the base on this phase as it might occur cosmetic damage during the sideways mounting operation.
The OP Frontal Assembly includes a calf support and a cushion, which is designed for OP Formula cockpits. For having excellent ergonomics in OP GT cockpits, a calf support is not required. If you choose to mount the calf support at any stage, follow the next few slides.
Page 40
Package: OP Frontal Assembly Attach screws (AB) to side boards with slides (E). Use washers (Y) to front slot.
Page 41
Package: OP Frontal Assembly Attach profiles (B) to the slides and tighten the screws.
Page 42
Insert slides (E) to profiles’ top slots Package: OP Frontal Assembly...
Page 43
Package: OP Frontal Assembly Attach Calf board (J) to slides inside profiles with screws (AB)
Page 44
Insert end caps (C) Package: OP Frontal Assembly...
Page 45
Insert Calf cushion (K) on top of calf board Package: OP Frontal Assembly...
