- Page 1 OP Formula Lite – Manual v0.1 – October 12th, 2020...
- Page 2 • Product includes small parts, please take special care if you have children in your household not to allow them to have access to the small parts. • If you encounter any issues or have any questions regarding our products, contact us at support@overpower.gg. We are happy to help you!
- Page 3 • After opening the boxes, check the parts received and compare them to the part list to make sure you have received all the parts for the product • In case there’s a part missing, contact us at support@overpower.gg...
-
Page 4: Part List
Part list (1/4) - Page 5 Part list (2/4)
- Page 6 Part list (3/4)
- Page 7 Part list (4/4)
- Page 8 Mount the reinforcement board (AJ) to 3060 profile (F) with M8 slides (E) and screws (AC)
- Page 9 Attach 3060 profile (F) to front board (M) with screws (AD)
- Page 10 Connect the reinforcement board (AJ) to front boards with screws (W), washers (BK) and slides (D)
- Page 11 Attach screws (AB) to side boards with slides (E). Use washers (Y) to front slot.
- Page 12 Attach profiles (B) to the slides and tighten the screws.
- Page 13 Insert slides (E) to profiles’ top slots...
- Page 14 Attach Calf board (J) to slides inside profiles with screws (AB)
- Page 15 Insert end caps (C)
- Page 16 Insert Calf cushion (K) on top of calf board...
- Page 17 Attach levers (X) to side boards with washers (Y) and sliders (E)
- Page 18 Attach profiles (A) to slides and put levers to the lowest position...
- Page 19 Insert slides (E) to profiles...
- Page 20 Attach wheel plate to profiles with screws (AB), washers and slides inserted in the previous phase...
- Page 21 Insert endcaps (C)
- Page 22 Attach pedal plate adapters (AF) to pedal side boards with screws (AR), washers (Y) and slides (E)
- Page 23 Attach pedal plate (LC) with screws (AB) and slides (E)
- Page 24 Attach pedal rack to frontal assembly with screws (4xAY) and slides (4xE).
- Page 25 Attach catches (L) with screws (Q)
- Page 26 In case you’re also installing OP Single or Triple Monitor Mount, insert two 3030 M8 Slides per outer profile slot (G) (total of 4 slides) Attach 3090 profile (G) to front side boards with screws (AD) and washers (Y).
- Page 27 Insert slides (BB) to 2020 profiles (BA)
- Page 28 Attach top profile (BA) with levers (BJ) and washers (BK)
- Page 29 Attach profiles (BA) with M6x40 screws (BN)
- Page 30 Attach profiles (BA) with levers (BJ) and washers (BK)
- Page 31 Attach profiles (BA) to side boards with M6x40 screws (BN) and washers (BK)
- Page 32 Attach Cushion holders (BE) to Seat base (BO)
- Page 33 Attach the Seat base (BO) to the seat with screws (BL) and M6 Slides inserted in earlier phase. Start from middle and work your way to top, and then bottom.
- Page 34 Turn the seat carefully sideways or upside down on a soft surface, and insert the Backboard (BC) to seat slots...
- Page 35 Attach Cushion (BD)
- Page 36 Attach handles (BF & BG) with screws (BM)
- Page 37 Attach U-covers (BR). Slide them in starting from left to right.
- Page 38 Attach latches (BH) using screws (BI)
- Page 39 Attach seat to front assembly with latches. Adjust the latches to have firm connection between the seat and front.
