- Page 1 OP GT Lite – Manual v0.1 – October 12th, 2020...
- Page 2 • Product includes small parts, please take special care if you have children in your household not to allow them to have access to the small parts. • If you encounter any issues or have any questions regarding our products, contact us at support@overpower.gg. We are happy to help you!
- Page 3 • After opening the boxes, check the parts received and compare them to the part list to make sure you have received all the parts for the product • In case there’s a part missing, contact us at support@overpower.gg...
-
Page 4: Part List
Part list (1/3) - Page 5 Part list (2/3)
- Page 6 Part list (3/3)
- Page 7 Mount the reinforcement board (AJ) to 3060 profile (F) with M8 slides (E) and screws (AC)
- Page 8 Attach 3060 profile (F) to front board (M) with screws (AD)
- Page 9 Connect the reinforcement board (AJ) to front boards with screws (W), washers (BK) and slides (D)
- Page 10 Attach levers (X) to side boards with washers (Y) and sliders (E)
- Page 11 Attach profiles (A) to slides and put levers to the lowest position...
- Page 12 Insert slides (E) to profiles...
- Page 13 Attach wheel plate to profiles with screws (AB), washers and slides inserted in the previous phase...
- Page 14 Insert endcaps (C)
- Page 15 Attach pedal plate adapters (AF) to pedal side boards with screws (AR), washers (Y) and slides (E)
- Page 16 Attach pedal plate (LC) with screws (AB) and slides (E)
- Page 17 Attach pedal rack to frontal assembly with screws (4xAY) and slides (4xE).
- Page 18 Attach catches (BH) with screws (BI)
- Page 19 In case you’re also installing OP Single or Triple Monitor Mount, insert two 3030 M8 Slides per outer profile slot (G) (total of 4 slides) Attach 3090 profile (G) to front side boards with screws (AD) and washers (Y).
- Page 20 Attach backboard to 3060 profiles...
- Page 21 Prepare 3030 corner brackets...
- Page 22 Attach corner brackets to 3030 profiles using the slides. Observe the orientation of the brackets from above.
- Page 23 Attach the 3030 profiles to 3060 profiles with corner brackets.
- Page 24 Insert slides to 3060 profile top slot.
- Page 25 Mount the HPL seat base with screws and slides inserted in the previous phase...
- Page 26 Attach screws and slides with washers to side board slots...
- Page 27 Attach latches to side boards...
- Page 28 Attach seat base to side boards...
- Page 29 Loosen the side board screws and attach seat base to frontal assembly...
- Page 30 Tighten the side board screws...
- Page 31 Unmount the seat base, turn it sideways, mount the seat of your choosage and start racing! Be careful with handling the base on this phase as it might occur cosmetic damage during the sideways mounting operation.
-
Page 32: Calf Support
Calf support The OP Frontal Assembly includes a calf support and a cushion, which is designed for OP Formula cockpits. For having excellent ergonomics in OP GT cockpits, a calf support is not required. If you choose to mount the calf support at any stage, follow the next few slides. - Page 33 Attach screws (AB) to side boards with slides (E). Use washers (Y) to front slot.
- Page 34 Attach profiles (B) to the slides and tighten the screws.
- Page 35 Insert slides (E) to profiles’ top slots...
- Page 36 Attach Calf board (J) to slides inside profiles with screws (AB)
- Page 37 Insert end caps (C)
- Page 38 Insert Calf cushion (K) on top of calf board...
