OP Formula – Manual
v0.3 - September 14th, 2020

Advertisement

loading
Need help?

Need help?

Do you have a question about the OP Formula and is the answer not in the manual?

Questions and answers

Related Manuals for OverPower OP Formula

Summary of Contents for OverPower OP Formula

  • Page 1 OP Formula – Manual v0.3 - September 14th, 2020...
  • Page 2 • Product includes small parts, please take special care if you have children in your household not to allow them to have access to the small parts. • If you encounter any issues or have any questions regarding our products, contact us at support@overpower.gg. We are happy to help you!
  • Page 3 • After opening the boxes, check the parts received and compare them to the part list to make sure you have received all the parts for the product • In case there’s a part missing, contact us at support@overpower.gg...

  • Page 4: Part List

    Part list (1/4)
  • Page 5 Part list (2/4) *Catch is packed together with Latch (BH), which can be found from the seat package HC 1...
  • Page 6 Part list (3/4)
  • Page 7 Part list (4/4)
  • Page 8 In case you’ll use OP Electric Pedal Adjuster, insert two additional 3030 M8 Slides (E) to lower slot of the profile (F) Mount the reinforcement board (AJ) to 3060 profile (F) with M8 slides (E) and screws (AC)
  • Page 9 Attach 3060 profiles (F) to front board (M) with screws (AD)
  • Page 10 Insert slides (D) to front 3060 profiles. Make sure to insert them in the slots shown above.
  • Page 11 Attach the front board (N) with screws (AD) to 3060 profiles.
  • Page 12 Connect the reinforcement board (AJ) to front boards with screws (W), washers (BK) and slides (D)
  • Page 13 Attach screws (AB) to side boards with slides (E). Use washers (Y) to front slot.
  • Page 14 Attach profiles (B) to the slides and tighten the screws.
  • Page 15 Insert slides (E) to profiles’ top slots...
  • Page 16 Attach Calf board (J) to slides inside profiles with screws (AB)
  • Page 17 Insert end caps (C)
  • Page 18 Connect linear guides (O) to 3060 profiles using M6 Slides (D) and screws (T). Before you tighten the guides, align the distance between the guide and side plate with jig (HC) included.
  • Page 19 Attach the blocks (H) to pedal side plates (AG & AH) with screws (U)
  • Page 20 Attach pedal rack cross support...
  • Page 21 Attach the pedal plate adapters (AF) to pedal side plates with screws (AA) and slides (E)
  • Page 22 In case you are installing OP Electric Pedal Adjuster, after completing this phase follow it’s manual to insert crossbar. Attach the pedal plate (AE) to pedal plate adapters (AF) using screws (AB) and slides (E)
  • Page 23 Slide the pedal rack to linear guides...
  • Page 24 Tighten the blocks to guides with M6 Levers (R)
  • Page 25 Attach levers (X) to side boards with washers (Y) and sliders (E)
  • Page 26 Attach profiles (A) to slides and put levers to the lowest position...
  • Page 27 Insert slides (E) to profiles...
  • Page 28 Attach wheel plate (AM) to profiles with screws (AB), washers (Y, note that washers are not shown in the picture) and slides inserted in the previous phase...
  • Page 29 Insert endcaps (C)
  • Page 30 Attach catches (L) with screws (Q)
  • Page 31 Insert Calf support (K) on top of calf board...
  • Page 32 In case you’re also installing OP Single or Triple Monitor Mount, insert two 3030 M8 Slides per outer profile slot (G) (total of 4 slides) Attach 3090 profile (G) to front side boards with screws (AD) and washers (Y).
  • Page 33 Insert slides (BB) to 2020 profiles (BA)
  • Page 34 Attach top profile (BA) with levers (BJ) and washers (BK)
  • Page 35 Attach profiles (BA) with M6x40 screws (BN)
  • Page 36 Attach profiles (BA) with levers (BJ) and washers (BK)
  • Page 37 Attach profiles (BA) to side boards with M6x40 screws (BN) and washers (BK)
  • Page 38 Attach Cushion holders (BE) to Seat base (BO)
  • Page 39 Attach the Seat base (BO) to the seat with screws (BL) and M6 Slides inserted in earlier phase. Start from middle and work your way to top, and then bottom.
  • Page 40 Turn the seat carefully sideways or upside down on a soft surface, and insert the Backboard (BC) to seat slots...
  • Page 41 Attach Cushion (BD)
  • Page 42 Attach handles (BF & BG) with screws (BM)
  • Page 43 Attach U-covers (BR). Slide them in starting from left to right.
  • Page 44 Attach latches (BH) using screws (BI)
  • Page 45 Attach seat to front assembly with latches. Adjust the latches to have firm connection between the seat and front.
