Summary of Contents for InFocus Play Big IN1
- Page 1 Audio Module Quick Start and Reference Guide...
-
Page 2: The Projector
Here's what's included: Audio Module Connect the audio module to the projector Make sure the projector is turned off and the power cord is unplugged before connecting or disconnecting the module. Outline Audio/video cables are not included. You can buy them at www.infocus.com/store or from... -
Page 3: Video Source
Connect to the component video source Connect video with a www.infocus.com/store part number SP-CPNT-10M Connect audio with an www.infocus.com/store part number SP-RCAAUD-5M s-video The video source controls which audio input is used When the displayed video source is component (red, blue, green), the module plays audio from the R and L (red and white) connectors on the module. - Page 4 Place the module on a firm flat surface and turn off and unplug the projector. Press in the release button under the front of the module. Lift the front of the projector up slightly. Lift the projector completely off the module. Replace the rubber connector cover on the bottom of the projector.
-
Page 5: Troubleshooting
The audio module is not correctly communicating with the projector. Turn off and unplug the projector, disconnect and re-connect the audio module, then plug in the projector and turn it back on. If the symbol is still shown, contact InFocus service at www.infocus.com/service... - Page 6 — Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. — Consult the dealer or an experienced radio/TV technician for help. Changes or modifications to this equipment that are not expressly approved by InFocus Corp. may void the user’s authority to operate the equipment.
