- Page 1 User Manual iv3600 MPS-3600H Series Programmable DC Power Supplyl I ps series programmable straight MPS-3600H series programmable DC power supply MATRIX TECHNOLOGY INC. Version No.: 20200506V1...
-
Page 2: Table Of Contents
Catalog CHAPTER 1 PRODUCT INTRODUCTION..........................1 CHAPTER 2 TECHNICAL SPECIFICATION.........................2 2.1 MAIN SPECIFICATION............................. 2 2.2 ADDITIONAL FEATURES............................2 CHAPTER 3 QUICK START..............................3 3.1 FRONT/REAR PANNEL INTRODUCTION.......................3 3.2 PRE-EXAMINE................................5 3.3IF THE POWER FAILS TO START..........................5 CHAPTER 4 PANEL OPERATION............................6 4.1 KEYBOARD ARRANGEMENT...........................6 4.2 FRONT PANEL OPERATION INTRODUCTION.......................7 4.3 VOLTAGE SETTING OPERATION..........................7 4.4 CURRENT SETTING OPERATION.......................... -
Page 3: Chapter 1 Product Introduction
Chapter 1 Product Introduction The MPS-3600H series is a new generation of high quality programmable DC power supply. This series of products is equipped with RS232 communication interface. The MPS-3600H series power supply has both desktop and system characteristics. It can be matched with... -
Page 4: Additional Features
This chapter will briefly introduce the appearance and basic functions of MPS-3600H series power supply, so that you can quickly understand the power supply of MPS-3600H series. At the same time, we will tell you the basic inspection to ensure the normal operation of this product after getting the power supply. - Page 5 2. The lower part of the front panel is 0-9 numeric keys and ESC exit keys from left to right, function keys, up and down movement keys and Enter keys, input and output terminals. MPS-3600H series rear panel layout, as shown below. Fig. 3.2 rear panel of MPS-3600H series power supply ① Sense(remote range port)
-
Page 6: If The Power Fails To Start
② Cooling hole ③ Serial No. ④ Power input switching. ⑤ RS232 communication interface ⑥ Power input socket 3.2 Pre-check Please check the power supply according to the following steps to ensure that the power supply can be used normally. 1. -
Page 7: Chapter 4 Panel Operation
2. ways to replace fuse Use screwdriver to open the small plastic cover below the power input socket of the power supply, you can see the fuse, please use the fuse with the same specification. Chapter 4 Panel Operation. This chapter will detail the operation of the power front panel, which is divided into the following parts: Keyboard arrangement ◆... -
Page 8: Front Panel Operation Introduction
"8"): lower limit set (and shift combination is effective when pressed). CRL (function word key Not open "Save"): I-Set Set the maximum output current of the power supply. V-Set Setting the output voltage of the power supply Save Store the relevant parameters of the power supply to the specified storage location. -
Page 9: Battery Charging Warning Function
Method 1: operation steps ①. Press the I-Set key. ②, press the 0 to 9 numeric keys to input the current value you need. ③. Press Enter key to confirm. Method 2: change the setting value of the voltage through the rotation of the knob. (the knob is pressed to the inside, the screen flickers can rotate and set the voltage and current. -
Page 10: Chapter 5 Remote Operation Mode
OCP off (overcurrent protection enable switch, on turn on, off close, set by knob) OVP XXX (overcurrent protection value setting, set by numeric key, confirm "Enter" key) Sense off (voltage remote measurement enable switch, on turn on, off close, set by knob) Beep on (buzzer sound enable switch, on turn on, off close, set by knob) Baud xxxx (communication baud rate setting, 4800-15200, set by knob) - Page 11 Chapter 6 SCPI communication protocol. 6.1 SCPI command overview MPS-3600H series programmable DC power supply supports SCPI communication protocol.Scpi is a standard command for programmable instruments. It defines a set of command rules for communication. Commands for iv3600 series power are divided into two main categories: basic command (ieee-488.2 common command set) and...
-
Page 12: Basic Command
under the AA root path is accessed. This command can also send multiple commands at the same time, separating the commands with semicolons (()). For example: []aa:bb:ee; FF; GG represents EE, FF, gg. under BB. [:]aa:bb:ff:: aa:dd:hh represents hh. under FF and DD under BB access. There are two types of mnemonic characters in SCPI language, that is, keywords, long format and short format. - Page 13 The power returned commands are "0,'No Error'", or "50,'Error Para Count'", or "70,'Invalid Command'" and so on. Order [:]SYSTem:REM The command is used to set up the power supply for remote control mode, that is, PC control mode. Return command: None Example: send the command to [:] SYST:REM <LF>...
- Page 14 At this point, the power return command is 1.245, which means the current supply current value is 1.245a. Order []MEASure:VC:? The command is used to read two measurements at a time: output voltage and output current. Returns the command: numeric list, separated by commas in the middle. Return parameters: V and a Example: the order sent is: [:] MEAS:VCM?
- Page 15 Example: 1) send the command to [:] CURR 3.000 <LF> That means the current value of the power supply is 3a.. 2. Related commands: inquire about the current setting value of the power supply. [:]CURR? MAX|MIN Return command parameter: numeric value Example: 2) If you want to inquire about the current setting value of the power supply, that is, the order sent is: [:]...
- Page 16 Certification and quality assurance The MPS-3600H series of programmable DC power reaches all the technical specifications specified in the manual. The company guarantees the quality and quality of this product for one year from the date of shipment. Maintenance service If the product is to be repaired, please send the product back to the designated maintenance unit of our company.
