- Page 1 ACJ006 V3.0 SW Lift Co ee Table wlive-cs@devaise.com...
-
Page 2: General Guidelines
IMPORTANT INFORMATION READ CAREFULLY. KEEP THIS INFORMATION FOR FURTHER REFERENCE. GENERAL GUIDELINES • • Please read the following instruction carefully and use the product accordingly. • Please keep this manual and hand it over when you transfer the product. This summary may not include every detail of all variations and considered steps. Please contact us when further information and help are needed. - Page 3 If you have any further questions, please feel free to contact us wlive-cs@devaise.com by email or official website: We will reply ASAP. Before installation, please make sure you have all the hardware, the serial numbers are properly labeled corresponging to the list, and the quantity is correct.
-
Page 4: Exploded Drawing
EXPLODED DRAWING PARTS M6x10 M6x60 M6x30 M4x14... - Page 5 REMARK MINIFIX POSITION M6x30 REMARK 1. Put a blanket under the board to avoid scratch or damage. 2. Please do not fully tighten screws. 3. Please pay attention to the part pointed out by the fingers, the side with the large holes should face up ×4...
- Page 6 M6x30 M6x60 REMARK 1. Please fully tighten all screws after all the screws are in place. 2. Please note the hole position of Part indicated by the fingers should face inside. ×4 M6x10 REMARK Please wait for 3 minutes until it glues completely. ×4...
- Page 7 REMARK Please do not screw too deep or too shallow. DEV ISE ×12 ×4...
- Page 8 ×12...
- Page 9 M4x14 REMARK Part have different lengths. Long Short...
- Page 10 M4x14 REMARK Please fully tighten all screws after all the screws are in place.
- Page 11 M4x14 REMARK Short Long 1. Please push the shadow part to the bottom and flip it. 2. Short shadow is the left, Long shadow is the right. M6x10 REMARK 1. Please push the part to the end. 2. Please ensure that the two countertops are aligned before tightening the screws.
- Page 12 M6x10 REMARK Please ensure that the two countertops are aligned before tightening the screws. ×4...
- Page 14 REMARK Please wait for 3 minutes until it glues completely. ×4 ×22...
