InFocus LP540 Replacement Instructions

Replacing the projection lamp

The lamp hour timer in the About menu counts the number of hours the
lamp has been in use. Fifty hours before the specified end of the lamp's life,
the message "Replace lamp" briefly appears on the screen at each startup
and in the Interactive Display. After 50 additional hours, the lamp will no
longer light. You can order new lamp modules from your dealer. See
"Accessories" on page 41 for information.
1 Turn off the projector and unplug the power cable.
2 Wait 60 minutes to allow the projector to cool thoroughly.
3 Turn the projector upside down and remove the lamp door by loosening
the captive screw and then prying the lamp door out.
4 Remove the two screws on the lamp module.

WARNINGS:

• To avoid burns, allow the projector to cool for at least 60 minutes before
you replace the lamp.
• Unplug the power cord before replacing the lamp.
• Do not drop the lamp module. The glass may shatter and cause injury.
• Do not touch the glass lamp screen. Fingerprints can obscure projection
sharpness.
About menu
R S-video 1
computer 1
computer 2 audio out
network serial control
audio in L video 2
audio in
monitor out
computer in video in
loosen the screw on lamp door
remove the screws on lamp module
turn off and unplug
the projector
wait 60 minutes
pry the lamp door off
