XTREME SERIES RALLY BAR
20" DUAL ROW LIGHT BAR
SPOT/FLOOD COMBO BEAM
MOUNTING INSTALL INSTRUCTION
SKU# 62233
INSTALL MANUAL
WHAT'S INCLUDED:
1 x LED Light Bar
§
Side and Bottom Mounting Brackets
§
Mounting Hardware
§
FEATURES & SPECIFICATIONS:
Light Output: 10,400 Lumens
§
LEDs: OSRAM
§
Power: 240W @ 13.6V DC
§
Current: 17.6A @ 13.6V DC
§
Voltage: 9 - 36V DC
§
Dimension (H,W,D): 2.8" x 22.0" x 2.0"
§
Beam Pattern: Spot/Flood Combo
§
1
WWW.ARC.LIGHTING
